AIR BAG JACKS

LTABJ2 and LTABJ3 are pneumatic portable jacks respectively with two and three
bellows. LTABJ2H and LTABJ3H come with a long handle with 2 position lock for
ease of maneuverability and storage.

These jacks are technically superior to what is currently in the market. They have a
telescopic stabilizer and are characterized by reduced dimensions and by a solid
and reliable structure. All five jacks are equipped with a safety valve and a stroke

limiting device.
Type-approved according to the European Standard EN1494
AIR BAG JACKS LTAB J2H
Manufactured in Europe
LTABJ12

LTABJ2 LTABJ3

Part Working Closed Lift Maximum Bellows Working Net Weight Dia. of
Load Limit Height Height pressure airbag
Number
LTABJ12 2,000kg 118mm 190mm 308mm 2 8-10bar 14kg 260mm
LTABJ2 2,000kg 132mm 194mm 326mm 2 8-10 bar 14kg 260mm
LTABJ2H 2,000kg 132mm 194mm 326mm 2 8-10 bar 16kg 260mm
LTABJ3 2,000kg 205mm 285mm 490mm 3 8-10 bar 17kg 260mm
LTABJ3H 2,000kg 205mm 285mm 490mm 3 8-10 bar 19kg 260mm

LIFTECH AIR OVER HYDRAULIC BOTTLE JACKS

Make lifting not only faster but more importantly
safe, as they allow one handed operation enabling
the user to watch the lifting and lowering of the
BOTTLE JACKS Feature: Uses standard workshop air supply, LT112AH LT120AH
load more closely.

designed for operating manually or pneumatically,
air hose can move in any direction, fitted with safety

valve against overloading, extension screw gives added
height when necessary.

Part Number Working Load Closed Height Lift Maximum Screw Net
Limit Height Height Weight
LT112AH 12,000kg 260mm 170mm 510mm 80mm 11kg
LT120AH 20,000kg 262mm 160mm 506mm 84mm 15.5kg
