Page 9 - 2020 Catalogue - Email_Neat

KARMOT PTY LTD 1300 527 668

LIFTECH LONG RAM JACKS

These top quality long ram jacks suit many applications but in particular mobile cranes.
Electro statically painted to prevent corrosion. 17mm Diameter bolt

Seal kits available for all models.

Each model has a choice of a flat or clevis pin base. i.e.
LT203 (Flat base), LT203SB (Swivel base).

LTA208SB now available air/hydraulic operated (swivel
base only).

LT203SB BOTTLE JACKS

LT203
17mm Diameter
LTA208SB

Part Number Working Load Closed Lift Maximum Ram Base Area Weight
Limit Height Height diameter

LT203/ LT203SB 3,000kg 590mm 480mm 1,070mm 28.5mm 115mmx100mm 9.6kg
LT205/ LT205SB 5,000kg 590mm 480mm 1,070mm 31.5mm 115mmx100mm 10.5kg

LT208/ LT208SB 8,000kg 614mm 484mm 1,098mm 34.5mm 115mmx100mm 14.5kg
LTA208SB 8,000kg 680mm 480mm 1,160mm 34.5mm 115mmx100mm 16kg

GARAGE JACKS

Liftech Garage Jacks are strong and reliable jacks, easy to use with a long service life

Features include:
 Universal joint release for trouble free operation.
 Frame designed for strength and durability.

 Wide wheel base for stability.
LT200TJN
 Both the LT200TLPN and LT200TJN have turbo lift to load.
 All approved to Australian Standards: AS 2615-2016.

LT200TLPN GARAGE JACKS
LT400

Part Working Closed Lift Max Maximum Overall Overall Net Weight
Number Load Limit Height Height Frame Height Length Width

LT200TLPN 2,000kg 68mm 432mm 508mm 145mm 710mm 390mm 36.5kg
LT200TJN 2,000kg 139mm 331mm 470mm 162mm 630mm 340mm 32kg
LT400 4,000 kg 140mm 460mm 600mm 240mm 885mm 400mm 88kg

sales@karmot.com www.karmot.com Page 3
