Page 116 - Donaldson - Exhaust product guide for medium and heavy-duty vehicles and equipment

Truck Engine Muffler Application
TRUCK ENGINE APPLICATION Engine Make & Model Engine H.P. Inlet Body Outlet Inlet Body Outlet Backpressure Notes

Muffler Dimensions
Exhaust System
inches of Muffler
inches
mm
Configuration
H 2 0 Style & Part No.
Hg

(8.7 LTA)

11.0
26
M120235 OE replacement

1.9
127 254x381 127
3

5.0
30

2.2
3
M120235 OE replacement
127 254x381 127
5.0

10x15
5.0
Series 40E
(8.7 LTA) 275 to 300 4.0 10x15 5.0 102 279 2.9 39 3 M111024 Outlet has down spout
Series 40E 320 5.0 10x15 5.0 127 254x381 127 2.3 31 3 M120235 OE replacement
(8.7 LTA)
International
DT817 385 4.0 8.5 4.0 102 216 102 1.7 23 1 M085171
4.0 9.0 5.0 102 229 127 2.4 33 1 M090781
5.0 9.0 5.0 127 229 127 2.0 28 1 M090074
5.0 9.0 5.0 127 229 127 1.1 15 1 M090535 Low backpressure, off-hwy
5.0 10.0 5.0 127 254 127 1.1 15 1 M100463 Low backpressure, off-hwy
5.0 10.0 5.0 127 254 127 2.2 30 1 M100465 Best value, most popular
5.0 10.0 5.0 127 254 127 2.3 31 1 M100580 OE replacement
5.0 10.0 5.0 127 254 127 2.5 34 1 M100807 60” (1524mm) Long Body
5.0 10.0 5.0 127 254 127 1.8 25 1 M100944 OE replacement for higher HP
5.0 10.0 5.0 127 254 127 2.2 30 1 M101158 Silent Partner Stainless
5.0 10.0 5.0 127 254 127 2.2 30 1 M101181 Silent Partner Aluminized
5.0 10.0 5.0 127 254 127 2.3 31 1 M101263 Freightliner only
5.0 11.0 5.0 127 279 127 1.8 25 1 M110849
DT812B 320 4.0 8.5 4.0 102 216 102 1.7 23 1 M085171
4.0 9.0 5.0 102 229 127 2.4 33 1 M090781
5.0 9.0 5.0 127 229 127 2.0 28 1 M090074
5.0 9.0 5.0 127 229 127 1.1 15 1 M090535 Low backpressure, off-hwy
5.0 10.0 5.0 127 254 127 1.1 15 1 M100463 Low backpressure, off-hwy
5.0 10.0 5.0 127 254 127 2.2 30 1 M100465 Best value, most popular
5.0 10.0 5.0 127 254 127 2.3 31 1 M100580 OE replacement
5.0 10.0 5.0 127 254 127 2.5 34 1 M100807 60” (1524mm) Long Body
5.0 10.0 5.0 127 254 127 1.8 25 1 M100944 OE replacement for higher HP
5.0 10.0 5.0 127 254 127 2.2 30 1 M101158 Silent Partner Stainless
5.0 10.0 5.0 127 254 127 2.2 30 1 M101181 Silent Partner Aluminized
5.0 10.0 5.0 127 254 127 2.3 31 1 M101263 Freightliner only
5.0 11.0 5.0 127 279 127 1.8 25 1 M110849
DT817C 420 4.0 8.5 4.0 102 216 102 1.7 23 1 M085171
4.0 9.0 5.0 102 229 127 2.4 33 1 M090781
5.0 9.0 5.0 127 229 127 2.0 28 1 M090074
5.0 9.0 5.0 127 229 127 1.1 15 1 M090535 Low backpressure, off-hwy
5.0 10.0 5.0 127 254 127 1.1 15 1 M100463 Low backpressure, off-hwy
5.0 10.0 5.0 127 254 127 2.2 30 1 M100465 Best value, most popular
5.0 10.0 5.0 127 254 127 2.3 31 1 M100580 OE replacement
5.0 10.0 5.0 127 254 127 2.5 34 1 M100807 60” (1524mm) Long Body
5.0 10.0 5.0 127 254 127 1.8 25 1 M100944 OE replacement for higher HP
5.0 10.0 5.0 127 254 127 2.2 30 1 M101158 Silent Partner Stainless
5.0 10.0 5.0 127 254 127 2.2 30 1 M101181 Silent Partner Aluminized
5.0 10.0 5.0 127 254 127 2.3 31 1 M101263 Freightliner only
5.0 11.0 5.0 127 279 127 1.8 25 1 M110849
DT817 385 4.0 9.0 4.0 102 229 102 1.0 14 1 M090544
4.0 10.3 4.0 102 262 102 2.0 27 1 M100464 Wrapped muffler
4.0 10.0 4.0 102 254 102 1.1 14 1 M100466
4.0 10.0 5.0 102 254 127 1.7 23 1 M100695
5.0 10.0 5.0 127 254 127 1.3 18 1 M100582 OE replacement
5.0 10.0 5.0 127 254 127 1.3 18 1 M101159 Silent Partner Stainless
5.0 10.0 5.0 127 254 127 1.3 18 1 M101182 Silent Partner Aluminized
5.0 11.0 5.0 127 279 127 0.7 9 1 M110849
DT812B 320 4.0 9.0 4.0 102 229 102 1.0 14 1 M090544
4.0 10.3 4.0 102 262 102 2.0 27 1 M100464 Wrapped muffler
4.0 10.0 4.0 102 254 102 1.1 14 1 M100466
4.0 10.0 5.0 102 254 127 1.7 23 1 M100695
5.0 10.0 5.0 127 254 127 1.3 18 1 M100582 OE replacement
5.0 10.0 5.0 127 254 127 1.3 18 1 M101159 Silent Partner Stainless
5.0 10.0 5.0 127 254 127 1.3 18 1 M101182 Silent Partner Aluminized
5.0 11.0 5.0 127 279 127 0.7 9 1 M110849
DT817C 420 4.0 9.0 4.0 102 229 102 1.0 14 1 M090544
4.0 10.3 4.0 102 262 102 2.0 27 1 M100464 Wrapped muffler
4.0 10.0 4.0 102 254 102 1.1 14 1 M100466
4.0 10.0 5.0 102 254 127 1.7 23 1 M100695
5.0 10.0 5.0 127 254 127 1.3 18 1 M100582 OE replacement
