Page 117 - Donaldson - Exhaust product guide for medium and heavy-duty vehicles and equipment

Truck Engine Muffler Application

Engine Make & Muffler Dimensions Backpressure
Exhaust System Engine inches mm inches of Muffler TRUCK ENGINE APPLICATION
Configuration Model H.P. Inlet Body Outlet Inlet Body Outlet Hg H 2 0 Style & Part No. Notes

5.0 10.0 5.0 127 254 127 1.3 18 1 M101159 Silent Partner Stainless
5.0 10.0 5.0 127 254 127 1.3 18 1 M101182 Silent Partner Aluminized
5.0 11.0 5.0 127 279 127 0.7 9 1 M110849
6.9L 170 4.0 10.0 4.0 102 254 102 1.1 15 3 M100146
7.3L (T444) 175 4.0 10.0 4.0 102 254 102 1.3 17 3 M100146

9.0L 185 4.0 9.0 5.0 102 229 127 0.6 9 3 M090823
4.0 10.0 4.0 102 254 102 1.8 24 3 M100146
4.0 11.8 5.0 102 300 127 0.7 9 3 M120598
5.0 10.0 5.0 127 254 127 0.6 8 3 M100213
DT360 190 4.0 9.0 5.0 102 229 127 1.1 15 3 M090823
4.0 11.8 5.0 102 300 127 1.2 16 3 M120598
5.0 10.0 5.0 127 254 127 1.0 14 3 M100213
DT466E 195 to 275 4.0 9.0 5.0 102 229 127 1.7 22 3 M090823
4.0 11.8 5.0 102 300 127 1.7 24 3 M120598
5.0 10.0 5.0 127 254 127 1.5 21 3 M100213
DT414 220 4.0 9.0 5.0 102 229 127 0.7 9 3 M090823
4.0 10.0 4.0 102 254 102 1.9 26 3 M100146
4.0 11.8 5.0 102 300 127 0.7 10 3 M120598
5.0 10.0 5.0 127 254 127 0.6 9 3 M100213
DT420 225 4.0 10.0 4.0 102 254 102 1.6 21 3 M100146
6.9L 170 3.0 8.5 3.0 76 216 76 1.6 22 2 M085023
3.0 8.5 3.0 76 216 76 1.6 22 2 M085056
3.0 8.5 3.0 76 216 76 2.0 28 2 M085078
3.0 8.3x11.5 3.0 76 211x292 76 2.9 39 2 M090170
3.0 8.5x11.8 3.0 76 216x300 76 2.9 39 2 M090159 Wrapped muffler
3.5 8.5 3.0 89 216 76 1.5 20 2 M085008
3.5 8.3x11.5 3.5 89 211x292 89 1.1 15 2 M090158
3.5 8.3x11.5 4.0 89 211x292 102 0.7 9 2 M090680 OE replacement
3.5 8.5x11.8 3.5 89 216x300 89 1.1 15 2 M090210 Wrapped muffler
4.0 10.0 4.0 102 254 102 0.7 9 2 M100048 Aftermarket
4.0 11.0 4.0 102 279 102 0.7 9 2 M110012
4.0 11.0 4.0 102 279 102 0.6 8 2 M110189 OE replacement
4.0 8.3x11.5 3.5 102 211x292 89 1.1 15 2 M090538
4.0 8.3x11.5 4.0 102 211x292 102 0.7 9 2 M090280 Aftermarket, shorter than OE
4.0 8.3x11.5 4.0 102 211x292 102 0.6 9 2 M090534 Aftermarket, shorter than OE
4.0 10.3x15.3 4.0 102 261x389 102 1.0 14 2 M120197 Wrapped muffler, OE
7.3L (T444) 175 3.0 8.5 3.0 76 216 76 1.8 24 2 M085023
3.0 8.5 3.0 76 216 76 1.8 24 2 M085056
3.0 8.5 3.0 76 216 76 2.3 31 2 M085078
3.5 8.5 3.0 89 216 76 1.7 23 2 M085008
3.5 8.3x11.5 3.5 89 211x292 89 1.3 17 2 M090158
3.5 8.3x11.5 4.0 89 211x292 102 0.8 10 2 M090680 OE replacement
3.5 8.5x11.8 3.5 89 216x300 89 1.3 17 2 M090210 Wrapped muffler
4.0 10.0 4.0 102 254 102 0.8 10 2 M100048 Aftermarket
4.0 11.0 4.0 102 279 102 0.7 10 2 M110012
4.0 11.0 4.0 102 279 102 0.7 9 2 M110189 OE replacement
4.0 8.3x11.5 3.5 102 211x292 89 1.2 17 2 M090538
4.0 8.3x11.5 4.0 102 211x292 102 0.8 10 2 M090280 Aftermarket, shorter than OE
4.0 8.3x11.5 4.0 102 211x292 102 0.7 10 2 M090534 Aftermarket, shorter than OE
4.0 10.3x15.3 4.0 102 261x389 102 1.2 16 2 M120197 Wrapped muffler, OE
9.0L 185 3.0 8.5 3.0 76 216 76 2.5 34 2 M085023
3.0 8.5 3.0 76 216 76 2.5 34 2 M085056
3.0 11.0 4.0 76 279 102 0.7 9 1 M111029 OE replacement
3.5 8.5 3.0 89 216 76 2.4 33 2 M085008
3.5 8.3x11.5 3.5 89 211x292 89 1.8 25 2 M090158
3.5 8.3x11.5 4.0 89 211x292 102 1.1 15 2 M090680 OE replacement
3.5 8.5x11.8 3.5 89 216x300 89 1.8 25 2 M090210 Wrapped muffler
4.0 10.0 4.0 102 254 102 1.1 15 2 M100048 Aftermarket
4.0 11.0 4.0 102 279 102 1.1 14 2 M110012
4.0 11.0 4.0 102 279 102 1.0 13 2 M110189 OE replacement
4.0 10x15 4.0 102 254x381 102 0.8 11 2 M120100 Aftermarket, shorter than OE
4.0 8.3x11.5 3.5 102 211x292 89 1.8 24 2 M090538
4.0 8.3x11.5 4.0 102 211x292 102 1.1 15 2 M090280 Aftermarket, shorter than OE
4.0 8.3x11.5 4.0 102 211x292 102 1.0 14 2 M090534 Aftermarket, shorter than OE
4.0 10.3x15.3 4.0 102 261x389 102 1.7 22 2 M120197 Wrapped muffler, OE
5.0 10x15 5.0 127 254x381 127 0.6 8 2 M120365 Aftermarket

donaldsonfilters.com Exhaust Product Guide • 115
