National Electrical Price Guide

Assemblies
On Standard Box with WP Cover
Switch 15A Spec On Standard Box with WP Cover S3wp Brown
Qty Description Labor Cost Retail
3 #16-#10 Red Wire Nut .00 .39 .66
1 3W Brn 15A Back Wired Spec Switch .20 2.49 19.20
1 Cast Box Switch Cover-1G Vert .08 4.18 16.52
1 1/2"&3/4" KO 4"x1-1/2" Sq Drawn Box .10 .71 6.90
1 5/8" Rise 4" Sq 1G Device Ring .05 .49 4.50
1 6" #12 Pigtail .02 .28 2.35
.45 $8.54 $50.13
Switch 15A Spec On Standard Box with WP Cover S3wp Gray
Qty Description Labor Cost Retail
3 #16-#10 Red Wire Nut .00 .39 .66
1 3W Gry 15A Back Wired Spec Switch .20 2.49 19.20
1 Cast Box Switch Cover-1G Vert .08 4.18 16.52
1 6" #12 Pigtail .02 .28 2.35
1 5/8" Rise 4" Sq 1G Device Ring .05 .49 4.50
1 1/2"&3/4" KO 4"x1-1/2" Sq Drawn Box .10 .71 6.90
.45 $8.54 $50.13
Switch 15A Spec On Standard Box with WP Cover S3wp Ivory

Qty Description Labor Cost Retail
3 #16-#10 Red Wire Nut .00 .39 .66
1 3W Ivy 15A Back Wired Spec Switch .20 2.49 19.20
1 Cast Box Switch Cover-1G Vert .08 4.18 16.52
1 5/8" Rise 4" Sq 1G Device Ring .05 .49 4.50
1 6" #12 Pigtail .02 .28 2.35
1 1/2"&3/4" KO 4"x1-1/2" Sq Drawn Box .10 .71 6.90
.45 $8.54 $50.13
Switch 15A Spec On Standard Box with WP Cover Swp Brown
Qty Description Labor Cost Retail
3 #16-#10 Red Wire Nut .00 .39 .66
1 SP Brn 15A Back Wired Spec Switch .15 1.89 12.64
1 Cast Box Switch Cover-1G Vert .08 4.18 16.52
1 5/8" Rise 4" Sq 1G Device Ring .05 .49 4.50
1 1/2"&3/4" KO 4"x1-1/2" Sq Drawn Box .10 .71 6.90
1 6" #12 Pigtail .02 .28 2.35
.40 $7.94 $43.57
Switch 15A Spec On Standard Box with WP Cover Swp Gray
Qty Description Labor Cost Retail
3 #16-#10 Red Wire Nut .00 .39 .66
1 SP Gry 15A Back Wired Spec Switch .15 1.89 12.64
1 Cast Box Switch Cover-1G Vert .08 4.18 16.52
1 6" #12 Pigtail .02 .28 2.35
1 5/8" Rise 4" Sq 1G Device Ring .05 .49 4.50
1 1/2"&3/4" KO 4"x1-1/2" Sq Drawn Box .10 .71 6.90
.40 $7.94 $43.57
Switch 15A Spec On Standard Box with WP Cover Swp Ivory

Qty Description Labor Cost Retail
3 #16-#10 Red Wire Nut .00 .39 .66
1 SP Ivy 15A Back Wired Spec Switch .15 1.89 12.64
1 Cast Box Switch Cover-1G Vert .08 4.18 16.52
1 1/2"&3/4" KO 4"x1-1/2" Sq Drawn Box .10 .71 6.90
1 5/8" Rise 4" Sq 1G Device Ring .05 .49 4.50
1 6" #12 Pigtail .02 .28 2.35
.40 $7.94 $43.57
White in Block Wall with Plastic Plate

ASSEMBLIES CONTAINING CONDUIT ARE BASED ON 10' LENGTHS
COST COLUMN IS A NATIONAL AVERAGE AND SHOULD BE VERIFIED FOR YOUR AREA
