FAN-PEDIA SHAFT SEALS

Published by
Twin City Fan & Blower
©2017 TCF.COM

Single Ring Mechanical Shaft Seal

(Vendor Supplied)
Also Known As:
- Single Carbon Ring
- Floating Circumferential Carbon Ring Seal
Mounting Surface - Labyrinth Shaft Seal
(Typically Fan Housing)
- John Crane
- Flow Serve
- Eagle Burgmann
Shaft
Mounting Hardware
Mounting Studs (bolts welded inside housing),
Nuts, Cap Screws

Seal Housing

Split Carbon Ring

Cover Plate

PTFE Joint Sealant

113
