FAN-PEDIA SHAFT SEALS

Published by
Twin City Fan & Blower
©2017 TCF.COM

Stuffing Box Type Shaft Seal
Mounting Surface
(Typically Fan Housing) Also Known As:
- Grafoil Seal
- Packing Gland Seal
Shaft - Shaft Seal - Graphoil (Stuffing Box)
- Shaft Seal - Stuffing Box Type

Mounting Hardware
Threaded Mounting Rod w/ Nut Welded to
Inside Housing, Nuts

Outside Plate w/ Retaining Ring

Outer Rings - Carbon Yarn Packing

Inner Rings - Graphoil Split Rings

Inside Plate w/ Seal Housing

PTFE Joint Sealant

115
