Drilling tools
Twist drill, carbide tipped
Twist drill type H with soldered cemented carbide insert 4xD DIN 8037 Metal cutting tools
For hard machining up to 63 HRC
Typ
VHM N
4xD 118°
Application: Advantage:
Hard machining up to 63 HRC. Cemented carbide insert, K20, for a long service
life
Execution: Polished chip chamber for good chip removal
Twist drill with universal standard geometry, Long service life in hardened steel
soldered cemented carbide insert (K20) and
driving lug on the clamp shank
Application Steel (N/mm ) Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
2
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
11162 15 10
f hard 65 11162... f hard 65 11162...
HRC ID no. HRC ID no.
(mm/U) (mm/U)
mm mm mm mm mm mm
3 20 50 0.03 030 O. R. 7 40 80 0.07 070 O. R.
3.2 25 56 0.03 032 O. R. 7.5 40 80 0.08 075 O. R.
3.3 25 56 0.03 033 O. R. 7.8 40 80 0.08 078 O. R.
3.5 25 56 0.04 035 O. R. 8 40 80 0.08 080 O. R.
3.8 25 56 0.04 038 O. R. 8.5 50 90 0.08 085 O. R.
4 25 56 0.04 040 O. R. 9 50 90 0.09 090 O. R.
4.2 28 63 0.04 042 O. R. 9.5 50 90 0.09 095 O. R.
4.5 28 53 0.05 045 O. R. 9.8 56 100 0.09 098 O. R.
4.8 28 63 0.05 048 O. R. 10 56 100 0.09 100 O. R.
5 28 63 0.05 050 O. R. 10.2 56 100 0.09 102 O. R.
5.5 32 71 0.06 055 O. R. 10.5 56 100 0.09 105 O. R.
5.8 32 71 0.06 058 O. R. 11 56 100 0.1 110 O. R.
6 32 71 0.06 060 O. R. 12 63 112 0.1 120 O. R.
6.5 32 71 0.07 065 O. R. Unit price, €
6.8 40 80 0.07 068 O. R.
Prod. group 140
Twist drill set type N with soldered cemented carbide insert 4xD
for universal use up to 1500 N/mm and for machining hard materials up to 63HRC DIN 8037
2
Typ
VHM N
4xD 118°
Application: Advantage:
No. 11160: Universal use in all material groups up to Cemented carbide insert, K20, for a long service
a strength of 1500 N/mm2. life
No. 11162: Hard machining up to 63 HRC. Polished chip chamber for good chip removal
Execution: Rugged steel case protects the tool from damage
while allowing user-friendly access
Twist drill with universal standard geometry, No. 11160: Long service life in hardened steel
soldered cemented carbide insert (K20) and
driving lug on the clamp shank No. 11162: Inexpensive tool with a broad range
of uses
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
11160 70 60 40 40 25 130 180 120 100 100 85 80 20 20 20 10
11162 15 10
Composition of set Pitch of drill Ø Number of pieces in as- 11160... 11162...
sortment/set (PCS) ID no. ID no.
3.0-10.0 1 mm 8 900 O. R. 900 O. R.
Set price, €
Prod. group 140
