Drilling tools
Conical countersinks and deburrers

Number of cutting edges 11495... Metal cutting tools
(PCS) ID no.
mm mm mm mm
16 3.2 53 10 7 516 O. R.
Unit price, €
Prod. group 114
Conical countersink, 120°, HSS, multi-flute cutter
For universal use up to 1000 N/mm 2
MK
HSS
Application: Advantage:
For countersinking 120° in the material groups ƒ High number of flutes for quiet cutting
steel, non-ferrous metals and cast materials up to a performance
strength of 1000 N/mm . 2 ƒ Innovative cutting geometry provides for optimal
chip breaking
Execution: ƒ Very good cutting performance and surface quality
ƒ Profile-ground multi-flute countersink with straight (chatter-free)
cutter
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
11495530-550 30 20 10 10 40 50 20 20 40 40 30 20
Number of cutting edges 11495...
(PCS) ID no.
mm mm mm
25 7 112 MK 2 9 530 O. R.
40 12 140 MK 3 11 550 O. R.
Unit price, €
Prod. group 114
Hand deburrers 90° HSS
with 3 cutters

Z
HSS
3
Application: Advantage:
For 90° counterboring and deburring for the material ƒ radial relief ensures optimum chip breaking
groups of steel (stainless steel), non-ferrous metals, ƒ Ident. No. 111–125: Ident. No. 111–125
and (cast iron) up to a strength of 1000 N/mm . 2 ƒ innovative cutting geometry provides excellent
cutting performance and good finish quality
Execution: ƒ ergonomic plastic handle ensures good force
ƒ profile-ground triple-edge countersink with radial transmission
relief
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
11511111-125 ˜ ˜ š š ˜ ˜ ˜ ˜ ˜ ˜ ˜ š š
11511211-225 ˜ ˜ š š ˜ ˜ ˜ ˜ ˜ ˜ ˜ š š

Spot-facer Ø (mm) 11511... 11511... Spot-facer Ø (mm) 11511... 11511...
ID no. ID no. ID no. ID no.
11.5 111 O. R. 211 O. R. 20.5 120 O. R. 220 O. R.
12.4 112 O. R. 212 O. R. 23 123 O. R. 223 O. R.
15 115 O. R. 215 O. R. 25 125 O. R. 225 O. R.
16.5 116 O. R. 216 O. R. Unit price, €
19 119 O. R. 219 O. R.
ORION = Prod. group 103
a = Prod. group 114
90° manual deburring tool set, HSS, triple cutter with hexagonal shank
for universal use up to 1000 N/mm 2

Z
HSS
3
Application: Advantage:
For 90° counterboring and deburring for the mate- ƒ radial relief ensures optimum chip breaking
rial groups of steel (stainless steel), non-ferrous ƒ innovative cutting geometry provides excellent
metals, and (cast iron) up to a strength of 1000 N/ cutting performance and good finish quality
mm . 2
Technical Data:
Execution: ƒ Composition of set: 1 of each conical countersink
ƒ profile-ground triple-edge countersink with radial 8/10/11.5/15/20.5
relief on the blade
