Drilling tools
Solid carbide standard drill

Prod. group 134
Solid carbide twist drill sets
Metal cutting tools
Metal cutting tools
in metal box
Typ HA
VHM TiN N
3xD
Application: Advantage:
Standard geometry for use in the material groups of ƒ excellent all-round properties and precise cutting
steel, (stainless steel), non-ferrous metals, cast iron pattern
and special alloys up to a strength of 1300 N/mm . 2 ƒ universal use: lower tool costs and offers greater
Execution: flexibility
ƒ No. 11150: Standard solid carbide tool, universal ƒ cutting edge preparation minimises microfractures
in the blade
precision grinding in metal box
ƒ No. 11151: Standard solid carbide TiN tool with ƒ sturdy metal box protects the tool against damage
universal precision grinding in metal box.

No. 11151
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
11150 70 60 50 30 28 140 190 130 120 130 120 100 80 80 25 25 25
11151 80 70 60 32 30 150 200 140 150 150 130 100 80 90 30 30 30
Surface Uncoated TiN
Composition of set Number of pieces in as- Pitch of drill Ø 11150... 11151...
sortment/set (PCS) ID no. ID no.
1.0-10.0 10 1 mm 900 O. R. 900 O. R.
Set price, €
Prod. group 134
Twist drill, solid carbide 3xD DIN 6539
for universal use up to 1300 N/mm 2

Typ HA
VHM TiAlN N
118° 3xD
Application: Advantage: No. 11150
No. 11150: Standard geometry for use in steel ƒ Very good all-round properties and precise cutting
(stainless steel), non-ferrous metals, cast iron and behaviour
special alloys material groups up to a strength of ƒ No. 11150:
1300 N/mm . 2 ƒ Universal use: Tool costs minimised and greater
No. 11153: Standard geometry for use in the mate- flexibility No. 11153
rial groups steel (stainless steel), non-ferrous met- ƒ Cutting edge preparation minimises micro-frac-
als, cast materials and special alloys up to a strength tures on the cutter
of 1300 N/mm . 2 ƒ No. 11153:
Execution: ƒ Universal use: minimises tool costs and improves
flexibility
ƒ Standard solid carbide tool with universal precision ƒ Cutting edge preparation minimises micro-frac-
grinding tures on the flute
ƒ TiAlN coating for up to 50% longer service life
and dry processing in steel
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
11150 70 60 50 30 28 140 190 130 120 130 120 100 80 80 25 25 25
11153 80 70 60 32 30 150 200 140 150 150 130 100 80 90 30 30 30
Surface Uncoated TiAlN Surface Uncoated TiAlN
f steel 11150... 11153... f steel 11150... 11153...
1000 ˜ ID no. ID no. 1000 ˜ ID no. ID no.
(mm/U) (mm/U)
mm mm mm mm mm mm
0.5 3 20 0.02 005 O. R. 005 O. R. 2.2 13 40 0.07 022 O. R. 022 O. R.
0.6 3.5 21 0.02 006 O. R. 006 O. R. 2.3 13 40 0.07 023 O. R. 023 O. R.
0.7 4.5 23 0.02 007 O. R. 007 O. R. 2.4 14 43 0.07 024 O. R. 024 O. R.
0.8 5 24 0.02 008 O. R. 008 O. R. 2.5 14 43 0.07 025 O. R. 025 O. R.
0.9 5.5 25 0.02 009 O. R. 009 O. R. 2.6 14 43 0.08 026 O. R. 026 O. R.
1 6 26 0.03 010 O. R. 010 O. R. 2.7 16 46 0.08 027 O. R. 027 O. R.
1.1 7 28 0.03 011 O. R. 011 O. R. 2.8 16 46 0.08 028 O. R. 028 O. R.
1.2 8 30 0.03 012 O. R. 012 O. R. 2.9 16 46 0.08 029 O. R. 029 O. R.
1.3 8 30 0.03 013 O. R. 013 O. R. 3 16 46 0.09 030 O. R. 030 O. R.
1.4 9 32 0.05 014 O. R. 014 O. R. 3.1 18 49 0.09 031 O. R. 031 O. R.
1.5 9 32 0.05 015 O. R. 015 O. R. 3.2 18 49 0.09 032 O. R. 032 O. R.
1.6 10 34 0.06 016 O. R. 016 O. R. 3.3 18 49 0.09 033 O. R. 033 O. R.
1.7 10 34 0.06 017 O. R. 017 O. R. 3.4 20 52 0.09 034 O. R. 034 O. R.
1.8 11 36 0.06 018 O. R. 018 O. R. 3.5 20 52 0.09 035 O. R. 035 O. R.
1.9 11 36 0.06 019 O. R. 019 O. R. 3.6 20 52 0.09 036 O. R. 036 O. R.
2 12 38 0.06 020 O. R. 020 O. R. 3.7 20 52 0.09 337 O. R. 337 O. R.
2.1 12 38 0.07 021 O. R. 021 O. R. 3.8 22 55 0.09 038 O. R. 038 O. R.
