Pneumatic tools

„Wave“ grinding disk Ø 90 mm

• For professional usage in automotive and painting plants and for ve-
hicle preparation
• Easily removes adhesive residues from stickers, decorative trims, foil
lettering, cover strips and two-sided adhesive tapes
• Ideally suited for removing adhesive residues from rim weights
• Optimal coating performance with increased service life
• The wave shape ensures increased safety of usage due to self-coo-
ling
• Gentle to paint when used properly

Technical Data
Diameter: 90 mm
Coating width: 20 mm
Maximal permissible speed: 4,000 rpm
Connector thread: M 8 × 1,0
Weight: 0.160 kg

5353 7035 5
Article No.. Article Description QTY
5353 7035 5 "WAVE" GRINDING DISK Ø 90 MM 1

Note:
• Note the contact pressure of the grinding disk on the work surface
during operation
• Note the maximum speed 5353 7035 2
• Work surfaces should be as clean and dust-free as possible
Accessories:
• The adapter for grinding disks, Art.-No. 5353 7035 2, is recommen-
ded when using a drilling machine

Grinding disk Ø 90 mm

• For usage in automotive and painting plants and for vehicle prepara-
tion
• Removes adhesive residues from stickers, decorative trims, foil lette-
ring, cover strips and two-sided adhesive tapes
• Suited for removing adhesive residues from rim weights
• Gentle to paint when used properly

Technical Data
Diameter: 88 mm
Coating width: 15 mm
Maximal permissible speed: 2,000 rpm
Connector thread: M 8 × 1,0
Weight: 0.160 kg
5353 7035 1

Article No. Article Description QTY
5353 7035 1 ERASER DISC Ø 90MM 7035D 1
5353 7035 2 ADAPTER F. GRINDING DISK 7035D 1
Note:
• Note the contact pressure of the grinding disk on the work surface
during operation 5353 7035 2
• Note the maximum speed
• Work surfaces should be as clean and dust-free as possible
Accessories:
• The adapter for grinding disks, Art.-No. 5353 7035 2, is recommen-
ded when using a drilling machine

Technical data subject to change.
Availability subject to country specific rules and regulations. www.iconridge.com Source: Theo Förch GmbH & Co. KG 1357
