• 11 : Triple 3-input AND gate

• 12 : Triple 3-input

• 413 : Dual Schmitt trigger 4-input NAND gate

• 420 : Dual 4-input NAND gate

• 421 : Dual 4-input AND gate
• 425 : Dual 4-input NOR gate with strobe

• 427 : Triple 3-input NOR gate

• 430 : 8-input NAND gate

• 431 : Hex delay elements

• 432 : Quad 2-input OR gate

• 433 : Quad 2-input NOR buffer with open collector outputs
• 436 : Quad 2-input NOR gate (different pinout than 7402)

• 437 : Quad 2-input NAND buffer

• 438 : Quad 2-input NAND buffer with open collector outputs

• 439 : Quad 2-input NAND buffer

• 440 : Dual 4-input NAND buffer
• 441 : BCD to decimal decoder/NIXIE tube driver

• 442 : BCD to decimal decoder

• 443 : Excess-3 to decimal decoder

• 444 : Excess-3-Gray to decimal decoder

• 445 : BCD to decimal decoder/driver
• 446 : BCD to 7-segment decoder/driver with 30 V open collector outputs

• 447 : BCD to 7-segment decoder/driver with 15 V open collector outputs

• 448 : BCD to 7-segment decoder/driver with internal pullups

• 449 : BCD to 7-segment decoder/driver with open collector outputs

• 450 : Dual 2-Wide 2-input AND-OR-INVERT gate (one gate expandable)
• 451 : Dual 2-Wide 2-Input AND-OR-INVERT gate

• 452 : Expandable 4-Wide 2-input AND-OR gate

• 453 : Expandable 4-Wide 2-input AND-OR-INVERT gate
