The two impedances are of the form, Z = R + jX and Z = R – jX C
L
1
1
2
2
Z is composed of a resistor and an inductor while Z is composed of a
2
1
resistor and a capacitor.
Figure 3.54
We may calculate, and and then add I and I to get I.
2
1
Alternately, we may find the equivalent impedance of the circuit, Z and then
find,
