Jack Hammer

Pneumatic Jack Hammer
‫همر تكسير الهواء‬

Model TPB-30 TPB-60 TPB-90
Piston Dia (Mm) 44.45 57.15 66.67
Piston Stroke (Mm) 100
Weight (Kg) 85 30 152
Overall Length (Mm) 15 645 42
Blow Per Min (Bpm) 564 1,400 723
Shank Size Hex (In) 1,550 1,250
Air Cons (M³/Min) H 1×4-¼ H 1-¼×6 H 1-¼×6
Air Inlet (Npt) 1.4 2.0 2.2
Hose Size (Mm) 3 /8 3/ 4 3/ 4
12.7 19 19

Gasoline Rock Drill
‫دريل تخريم بنزين‬

Model YN27C
Weight 27kg
overall dimension 746*315*229mm
engine single cylinder, air cooled two strokes
Cylinder diameter*stroke piston 58*70mm
Rotating speed of engine more than 2450r/min
displacement of engine 185cm^3
carburetor hand needle valve, no floating type
Ignition system controllable silicon contactless system
Drilling speed more than 2450r/min
Max drilling depth 6M
Fuel consumption 1.2L/min
Tank capacity more than 1:14L
mixing ratio of gasoline and lubrication oil 12:01
end of drill rod dimensions hexagonal 22*108mm
Rotating speed of drill rod more than 200r/min
Clearance of spark plug 0.50.7-mm

Pneumatic Hammer
‫همر تكسير الهواء‬

Piston Diameter Piston Stroke Blow per Min Net Weight Overall Length Avg. Air Cons Air Inlet Air Inlet
(mm) (mm) (bpm) (kg) (mm)
Model 20 50 3.600 2.0 254 m3/min cfm mm pt mm pt
AA-0B 24 58 2.800 4.5 320 0.35 12.4 9.5 3/ 8 12.7 1/ 2
AA-1.3B 28 79 2.400 5.8 330 0.45 15.9 9.5 3/ 8 12.7 1/ 2
AA-3B 28.54 102 1.800 7.0 480 0.45 15.9 9.5 3/ 8 12.7 1/ 2
THA-4S RV 0.95 33.5 9.5 3/ 8 12.7 1/ 2
