Construction Equipment

Tamping Rammer
Tamping Rammer
‫رصاصة تراب عمودي‬

MODEL MT-76D MODEL MT-72FW
Weight (KG) 82 Weight (KG) 74
Dimension(mm) L: 740 W: 410 H: 1010 Dimension(mm) L: 730 W: 415 H: 1070
Plate Size (mm) L: 285 W:340 Plate Size (mm) L: 285 W:340
Jumping Stoke (mm) 50- 80 Jumping Stoke (mm) 50- 75
Impact Force KN (kgf) 15.7 (1600) Impact Force KN (kgf) 13.7 (1400)
Impact Number Per Min. 656 -698 Impact Number Per Min. 642 -679
Fuel (Capacity) Diesel [3.3L] Fuel (Capacity) Gasoline [2.5L]
Power Source KW (PS) Yanmar L48N max. Power Source KW (PS) Subaru EH122-D max.
output 3.5(4.7) output 2.6(3.5)
