P. 113

IRONWORK



           Cargo Control

                                                                                                                     ELECTRICAL

           Sprung Shoring Poles                                Heavy Duty Track — Zinc Plated

           „  Part No. 1815 - suitable for track to track width 2200mm to   „  Hole size 25mm diameter.
             2300mm.                                           „  Fixing holes 7mm diameter.
           „  Part No. 1819 - adjustable for track to track width 2130mm to   „  Drainage holes top and bottom meaning that the track can be
             2590mm in 75mm increments.                          mounted horizontally either way up
           „  Part No. 1815 - can easily be trimmed to shorter lengths if                                            EMERGENCY
             required.
           „  32cm of Spring.

                                                                                                                     GENERAL








                                                                                                                     HANDLES

          Part No.  A  B                            Kg  Finish
          1815    2350 42                           6.98  ZP
          1819    2590 42                          6.975  ZP
                                                               Part No.  A  B  C   D   E                Kg  Finish
           Standard Track                                      1806   3000 80  41  13  3                3.545  ZP    HINGES


           „  Hole size 25mm diameter.
           „  Fixing holes 4mm diameter.                       Heavy Duty Track — Stainless Steel

                                                               „  Hole size 25mm diameter.
                                                               „  Fixing holes 7mm diameter.
                                                               „  Drainage holes top and bottom meaning that the track can be   IRONWORK
                                                                 mounted horizontally either way up



                                                                                                                     LIGHTING




          Part No.  A  B   C  D   E                 Kg  Finish
          1805    3000 68  41  15  2               2.945  ZP
                                                                                                                     LOCKS
           Butterfly Hook For 1806 Track






                                                               Part No.  A  B  C   D   E                Kg  Finish
                                                               1806SS  3000 80  41  15  2               3.545  SS    STEPS



                                                                                                                     VENTILATION


          Part No.                                  Kg
          1806-BH                                  0.195



                                  +44 (0) 1454 319524     sales@stedall.co.uk     www.stedall.co.uk               111
