LIGHTING



           Strobe Lights

                                                                                                                     ELECTRICAL

           LED Beacon — Amber                                  LED Light Bar — Amber

           „  Low profile amber warning beacon.                „  Excellent 360 degree light coverage over a wide area.
           „  ECE R65 /R10 Compliant.                          „  Max output 40 Watts.
           „  3 year warranty.                                 „  ECE R65 & R10 Compliant.
           „  Dual Voltage 12/24v Output 27 watt.              „  UV resistant clear polycarbonate lens.             EMERGENCY
           „  IP rating 67.                                    „  Dual Voltage 10-30v.
           „  Screw fixing, plant on.                          „  10 flash patterns.
           „  10 flash patterns.

                                                                                                                     GENERAL








                                                                                                                     HANDLES







                                                                                                                     HINGES
          Part No.  A  B   C                        Kg  Voltage  Part No.  A  B  C  D  E   F            Kg  Voltage
          7855    112  47  88                       0.35 12/24v  7840  285 178  40  35  236 142         1.365 10-30v



           LED Corner Strobe Light — Very Wide Angle           Covert HideAway

           „  LED: 5 SMD LED`s                                 „  Super low profile Aluminium Body with Clear Polycarbonate
           „  LED Colour: Amber Voltage: 10~30                   Lens.                                               IRONWORK
           „  IP Rating: IP67                                  „  Single and Dual Colour, 6 Led’s with 14 flash patterns.
           „  Approvals: ECE R65, EMC R10                      „  50% Dimable function and syncable.
           „  10 Flash Patterns                                „  Gromet fixing. IP67
           „  This product is supplied with a Stainless Steel right angled
             mounting bracket, that can be fixed in either direction.
           „  This light can also be mounted directly to a flat surface.                                             LIGHTING
           „  The lamp has a 140 Deg spread and therefore fitting one  to
             each corner of a vehicle will provide far greater than 360
             degree light coverage.


                                                                                                                     LOCKS







                                                                                                                     STEPS


                                                               Part No.  A  B  C   D        Colour      Kg  Voltage
                                                               7865-1  34  30  25  24        Red        0.055 12/24v
                                                               7865-2  34  30  25  24        Blue       0.055 12/24v
                                                               7865-3  34  30  25  24       Amber       0.05 12/24v
          Part No.  A  B   C  D        Colour       Kg  Voltage  7865-4  34  30  25  24    Red/Blue     0.065 12/24v  VENTILATION
          7856    175  38  54  162      Amber      0.365 10/30v  7865-5  34  30  25  24    Blue/White   0.06 12/24v
