LIGHTING

Indicator Lights

ELECTRICAL

R23 LED Safety Reverse/Work Light PRODUCT FOCUS

„ ECE R10 R23 Led Light for Manoeuvring / Perimeter and
Reverse.
„ 10 – 30V 4 x 2 Watt Cree LED`s B
„ 105 Deg Wide Angle of beam and 65 Deg depth of beam.
„ PC Front Cover and Aluminium Body. A EMERGENCY
„ Waterproof: IP69k
C
More info online
D
GENERAL
Part No. A B C D E Kg Finish
218-5 182 72 23 165 30 0.315 BP

LED Stop Tail Indicator Lamp LED 3rd Brake Mount

„ Recessed LED 3rd Brake Light
„ Part No 364-3 Surface mount adapter for 364-1 and 364-2 HANDLES
A

B
D
HINGES
C

IRONWORK
Part No. A B C D Type Kg Voltage Part No. A B C D E Kg Voltage
8135-1 135 38 24 80 Surface Mount 0.145 12/24v 364-1 277 25 20 5 260 0.12 12v
8135 135 38 24 80 Semi Recessed 0.145 12/24v 364-2 277 25 20 5 260 0.13 24v
8135LP 95 36 80 Vac Formed Light Pod 0.065 364-3 277 25 20 260 0.035

LED Number Plate Light LED Reversing Lamp LIGHTING

„ Dual voltage „ LED Worklamp/Reversing Lamp.
„ screw fixing, plant on. „ Can legally be used as a reverse light.
„ Supplied with flying lead „ The lamp should be mounted vertically and as such the
spread of light will meet R23. EMC R10 Class 5 ECE R23
„ Raw Power 36 watts.
„ IP Rating IP69K. LOCKS
D

B

A
STEPS
C

VENTILATION

Part No. A B C D Kg Voltage Part No. A B C D E F Kg Voltage
219-1 72 45 45 45 0.055 12v 215-5 98 136 38 37 29 35 0.41 12v
