LIGHTING



          Exterior Lights




          LED Zone Lights — dual function with Blue Strobe                       PRODUCT FOCUS

    ELECTRICAL
          „  Sleek modern design blends in with the body panel of the vehicle. Dual function options
            available with built-in Blue strobe light. Clip-On cover.
          „  Zone Light Power: 32W Strobe Light Power: 12W
          „  930 Lux@ 1 Mtr.    Colour Temp 6900k
          „  Zone Light Angle: Down 45°.
          „  Synchronization & Asynchronous Standard.    Waterproof: IP6K9K
          „  Blue Flashing Patterns: 12 Patterns.    ECE Approval: ECE R65, EMC R10           More info online
    EMERGENCY
          „  Other Approval: CE, UKCA :- CISPR 25     Housing Material: Aluminium Housing, PC Cover
          „  Lens Material: UV Resistant PC Lens Lens Colour: Clear
          „  Mounting: Screw Mount.    Cable: 0.4M Cable
          „  Gasket: Rubber.    Warranty: 5 years
          „  Working Temp: -45°C ~ +65°C
    GENERAL






                                                                                                           B
    HANDLES
                                                                                               A


         Part No.  A  B   C  D      Frame Colour   Kg  Voltage
                                                                                    C L                    C
         210-2Y  225  37  68  190      Yellow     0.33 10/30v
    HINGES
         210-2B  225  37  68  190      Black      0.33 10/30v
                                                                                               D
         210-2W  225  37  68  190      White      0.33 10/30v

          Micro LED Zone Lights with Dim function

          „  Extremely compact high performance external light.
    IRONWORK
          „  Die cast aluminium body in powder coated black, with clip-on plastic covers in various colours to suit the vehicle.
          „  Comes as standard with 50% dim function, which is ideal for above door applications.
          „  Supplied with rubber gasket.
          „  10 Watt (5 Watt In dim mode).
          „  563 Lux@ 1Mtr 295 Lux in dim mode) Colour Temp 6500k.
    LIGHTING
          „  10 to 30 Volt.
          „  IP69K Waterproof.
          „  Approval: UKCA & CE & EMC.


    LOCKS




                                                                                                           B

    STEPS
                                                                                               A


         Part No.  A  B   C  D        Colour       Kg  Finish
                                                                                                           C
         210-3YM  115  23  37  95      Yellow     0.09
         210-3BM  115  23  37  95      Black      0.09
                                                                                               D
         210-3WM  115  23  37  95      White      0.09
    VENTILATION
