LIGHTING

Exterior Lights

ELECTRICAL

Stedpower LED Zonelight LED Zonelight

„ Zone Lamp for commercial applications with fixed angle „ Plant-On Zonelight designed to improve visibility in the
beam. external working environment as required by the Emergency
„ Can be used in a variety of external applications, including Services.
load lighting and illuminated wide areas around vehicles. „ 212 Anodised Silver, 212Y Painted Yellow, 212B Painted Black
„ Die Cast Aluminium, with Polycarbonate Diffuser. Surface „ 700 Lux @ 1Mtr Colour Temp 5900k EMERGENCY
Mount
„ IP Rating IP69K.
„ Lux @ 1Mtr 1290
„ Colour Temperature 6000k approx
GENERAL
„ Operating Temp. -30 + 60 °C.

A

B
HANDLES
D

C

C L
Part No. A B C D Kg Voltage
212 300 80 38 275 0.65 12/24v HINGES
Part No. A B C D E Kg Voltage 212Y 300 80 38 275 0.63 12/24v
218 250 57 30 232 36 0.52 12/24v 212B 300 80 38 275 0.66 12/24v

LED Mini Zonelight LED Micro Zonelight IRONWORK

„ Plant-On Zonelight designed to improve visibility in the „ High output Micro Zone Light
external working environment as required by the Emergency „ Long life 30,000 hours. Ra 76 Colour Temp 6000k approx
Services. Water proof (IP67) high quality manufacture with ABS body.
„ 212-1 Anodised Silver, 212-Y Painted Yellow „
„ Aluminium heatsink and PMMA lens.
„ 212B Painted Black, 212-1W Painted White
„ 12 X 0.5w giving 135 lux @ 1Mtr.
„ 600 Lux @ 1Mtr Colour Temp 5900k approx LIGHTING
„ Operating temperature -30°C – +85°C
A
B

D
C LOCKS

E C
STEPS
Part No. A B C D E Body Kg Voltage
212-1 200 55 38 187 2 Anodised Silver 0.35 12/24v
Aluminium
212-1Y 200 55 38 187 2 Painted Yellow 0.35 12/24v
Aluminium
212-1B 200 55 38 187 2 Painted Black 0.35 12/24v
Aluminium
Part No. A B C D E Kg Voltage VENTILATION
212-1W 200 55 38 187 2 Painted White 0.345 12/24v
Aluminium 212-4 117 55 38 104 2 0.195 12v

+44 (0) 1454 319524 sales@stedall.co.uk www.stedall.co.uk 133
