HINGES

Lift up Hinges

Lift Up Hinge — For Ramp Applications Lift Up Hinge — For Top Flap Applications

ELECTRICAL
„ Single Action Lift Up Hinge, for ramp applications „ Double Action Lift Up Hinge for flap applications
„ Operates using internal disc springs „ Operates using internal disc springs
„ No maintenance required „ No maintenance required
„ Springs can be adjusted by slightly unscrewing adjustment „ Springs can be adjusted by slightly unscrewing adjustment
plug to reduce torque significantly plug to reduce torque significantly
„ Mounted on the outside, there is no ingress into load area „ Mounted on the outside, there is no ingress into load area
and allows unhindered access for loading. Lifting torque 130 and allows unhindered access for loading. Lifting torque 140
EMERGENCY
NM NM

GENERAL

HANDLES

Part No. A B C D E F G H Kg Finish Part No. A B C D E F G H Kg Finish

SPU360SA 49 292 146 116 90 103 66 86 4.87 Grey SPU360DA 49 292 146 116 90 103 66 86 4.25 Grey

HINGES
Lift Up Hinge — For Top Flap Applications Lift Up Hinge Accessories

„ Double Action Lift Up Hinge for flap applications „ Black plastic end caps.
„ Operates using internal disc springs „ Part No. SPUECRH Black Plastic Right Hand End Cap
„ No maintenance required „ Part No. SPUECLH Black Plastic Left Hand End Cap
„ Springs can be adjusted by slightly unscrewing adjustment
plug to reduce torque significantly
IRONWORK
„ Mounted on the outside, there is no ingress into load area
and allows unhindered access for loading. Lifting torque 100
NM

LIGHTING

LOCKS

Part No. A B Kg Finish
Part No. A B C D E G H Kg Finish SPUECRH 63 67 0.045 BP
SPU180DA 49 192 146 116 90 66 86 3.33 Grey SPUECLH 63 67 0.045 BP
