HINGES

Butt Hinges

ELECTRICAL

Hinge — Nylon Stainless Steel Security Pin Hinge

„ Material: Nylon with stainless steel pin. „ 304 Grade of Stainless Steel Hinge.
„ Integrated Security Pin.
EMERGENCY
„ Concealed Bearings.
„ Options of “Z” Hole or “C” Hole patterns.
„ Image shows C pattern.

GENERAL

HANDLES
Part No. A B C D E F Kg Finish Part No. A B C D E F G H Kg Finish
9-00632 76 40 50 20 30 9 0.02 WN 1730-1 100 76 15 13 25 10 20 3 0.275 SS

Coach Hinge — Steel Hinge — Aluminium

„ Material: Mild Steel 4mm thick „ Fitted with zinc plated pin & PVC bushes HINGES
„ Supplied undrilled.

IRONWORK

LIGHTING

Part No. A B C D Kg Finish Part No. A B C D E Kg Finish
1710-1 50 63 50 15 0.2 SC 2737989 50 80 6 100 13 0.16 SC

Compact 4 Hole Hinge PRODUCT FOCUS

„ Both hinges are supplied with stainless LOCKS
steel pins that have rounded ends.
„ Tolerances have been reduced. Each
hinge has maintenance free special
grease in the pivot points, which aids D
smooth movement.
„ Universal fitting. STEPS
A
More info online

G
H
Part No. A B C D E F Description Kg Finish
C
273 50 70 13 15 10 3 ZP VENTILATION
B
274 50 70 13 15 10 3 SS
