HINGES



           Continuous Hinges

                                                                                                                     ELECTRICAL

           Continuous Hinge                                    Hinges — Side Locker

           „  180° Opening Hinge.
           „  Self coloured anodised aluminium.
                                                                                                                     EMERGENCY







                                                                                                                     GENERAL








                                                                                                                     HANDLES


                                                               Part No.  A  B   Description   Length    Kg  Finish
                                                               3720235  44  30  Top section     3m      1.045  AA
          Part No.  A  B   C  D   E   F   G   H     Kg  Finish  3720236  44  30  Bottom section  3m     1.175  AA
          2744400  2000 70  3.5  24  25  57  17  20  2.5  AA   4050003        Black EPDM insert  50m coil  13.69  BP
                                                                                                                     HINGES


           Hinges — Hytrel Continuous                          Hinge — Top Flap

           „  Supplied in 2.5 metre lengths.                   „  Anodised aluminium - supplied in 5 metre lengths.
           „  Rigid black one piece PVC extrusion with Hytrel hinge   „  Top hinge application.
             membrane.
                                                               „  155º opening.                                      IRONWORK
           „  Usually mounted in a horizontal plane.           „  Overall protrusion from body side is 20mm.
           „  160º opening.


                                                                                                                     LIGHTING
                                           A



                                                B



                                           C                                                                         LOCKS




          Part No.  A  B   C                        Kg  Finish
          SVF524   28  23  16                      1.385  BP   Part No.  A  B  C                        Kg  Finish
          SVF527   33  32  18                       2.34  BP   SVF525  28  28  13                       6.99  AA     STEPS



                                                                                                                     VENTILATION
