HINGES

Continuous Hinges

Hinge — Bottom Flap

ELECTRICAL
„ Anodised aluminium - supplied in 5 metre lengths.
„ Bottom hinge application.
„ 90º opening.

EMERGENCY

THIS ALARM CAN BE CONNECTED TO ANCILLARY LAMPS, AND
AS SUCH PROVIDES AN AUDIO AND VISUAL WARNING
GENERAL
MULTI FUNCTION

REVERSING ALARM

TWO BUILT IN WARNING
HANDLES
MESSAGES PLUS NIGHT MODE.

Part No. A B C Description Kg Finish
1636747 25 30 25 Bottom 3.975 AA
1636748 25 30 25 Top 3.44 AA
See page 14
HINGES

Continuous Hinge

„ Stainless grade 304
IRONWORK

Supplied undrilled 72" (1829mm)
LIGHTING

Part No. Width Open Width Closed Leaf Gauge Pin Gauge Kg Finish
LOCKS
5978-4 13/4” (44mm) 1” (25mm) 18 (1.2mm) 10 (3mm) 0.96 MS
5978-30 2” (50mm) 13/16” (30mm) 16 (1.5mm) 4 (5.9mm) 1.71 MS
5978-32 3” (75mm) 121/32” (42mm) 14 (2mm) 4 (5.9mm) 3.005 MS

5978-25 1” (25mm) 5/8” (16mm) 18 (1.2mm) 10 (3mm) 0.725 SS
STEPS
5978-26 11/2” (38mm) 7/8” (22mm) 18 (1.2mm) 10 (3mm) 1.015 SS
5978-27 2” (50mm) 15/32” (29mm) 18 (1.2mm) 7 (4.5mm) 1.285 SS
5978-28 21/4” (57mm) 15/16” (33mm) 16 (1.5mm) 4(5.9mm) 1.865 SS

5978-29 13/4” (44mm) 1” (25mm) 18 (1.2mm) 7(4.5mm) 0.41 AL
5978-33 21/4” (57mm) 15/16” (33mm) 16 (1.5mm) 4(5.9mm) 0.655 AL
