The midpoint circle algorithm exploits the symmetry of a circle to efficiently compute pixel positions for one octant and replicate
them across the remaining octants. This reduces redundant calculations and improves performance.
Curve drawing techniques are commonly based on parametric representations, where points on the curve are generated by varying
a parameter within a specified range. Such approaches allow smooth rendering of curves and are widely used in computer graphics
applications, including user interface design and geometric modeling.

2.13.3 Anti-Aliasing Techniques
When continuous geometric shapes are represented on a discrete pixel grid, visual artifacts such as jagged edges may appear, a
phenomenon known as aliasing. Anti-aliasing techniques are employed to reduce these artifacts and improve image quality.
Common anti-aliasing approaches include supersampling, where each pixel is subdivided into multiple sub-pixels and averaged, and
multisample anti-aliasing (MSAA), which selectively applies multiple samples along object edges. Filtering-based methods further
enhance smoothness by blending pixel intensities near boundaries.

Anti-aliasing techniques are essential in line and curve rendering, polygon edges, and text display, providing a
balance between visual quality and computational efficiency.

2.14 Polygon Filling and Clipping Techniques

Polygon filling and clipping are essential operations in raster-based computer graphics systems. Polygon filling determines the set
of interior pixels that should be displayed to represent a solid shape, while clipping restricts the displayed portion of a polygon to a
specified viewing region. These operations are fundamental for rendering complex scenes efficiently and accurately.

2.14.1 Seed Fill Algorithm
The Seed Fill Algorithm is a region-filling technique used to fill a connected area starting from a given interior point, known as the
seed. The algorithm examines neighboring pixels and fills them recursively or iteratively until a specified boundary is reached.
Two common variants of the seed fill algorithm are:
Four-connected fill, which considers the top, bottom, left, and right neighboring pixels.
Eight-connected fill, which also includes diagonal neighbors.
Seed fill algorithms are simple to implement and widely used in interactive graphics applications. However, their recursive nature
may lead to high memory usage for large regions, which can be mitigated by using iterative approaches.

2.14.2 Edge Flag Algorithm
The Edge Flag Algorithm is a scan-line-based polygon filling method. It operates by scanning each horizontal line across the polygon
and determining the intersections between the scan line and the polygon edges.
An edge flag is toggled whenever a scan line crosses a polygon edge, indicating whether pixels lie inside or outside the polygon.
Pixels between pairs of intersections are filled, producing a solid interior region.
This algorithm is efficient and well-suited for filling convex and concave polygons, making it commonly used in raster graphics
systems.

2.14.3 Polygon Clipping Algorithms
Polygon clipping algorithms are used to determine the visible portion of a polygon within a defined clipping window. These
algorithms remove or modify polygon edges that fall outside the viewing area.
A widely used polygon clipping method is the Sutherland–Hodgman algorithm, which clips a polygon against each boundary of the
clipping window sequentially. The resulting polygon preserves the shape of the visible region while discarding invisible portions.
Polygon clipping improves rendering efficiency and ensures that only relevant graphical data is processed and displayed.
