With the rod introducer : MS1-A274
TM
TM
Insert the rod (UNI-Thread rod [a] or LUMIS percutaneous rod
[b]) into the slot located at the end of the instrument, ensuring that
the end of the rod points up and away from the user.
(a) If the LUMIS percutaneous rod is
TM
used (MS1-R6xxxT/MS1-R6xxxCT),
(b) take care to insert the non-bulleted
extremity in the rod introducer.
Lock the rod in the instrument by tightening the locking
screw with the T30 shaft (MS1-A411) preassembled with the
dual purpose handle (U1-A622).
GMS2-ST_04GB See package insert for labeling limitation 35
