With the reversed rod introducer :
MS1-A275
Insert the rod into the slot located at the end of the instrument,
ensuring that the tip of the rod points up and towards the user.
A laser mark indicates which side the rod must be placed.
When the LUMIS TM percutaneous rod is used, take care to insert the
non bulleted extremity in the reversed rod introducer.
Extremity to insert into the
reversed rod introducer
Lock the rod in the instrument by tightening the locking
screw with the T30 shaft (MS1-A411) preassembled with
the dual purpose handle (U1-A622).
