With the rod introducer : MS1-A274
TM
Insert the rod beneath the muscles by inserting its tip (UNI-Thread
TM
rod) or bullet nose (LUMIS percutaneous rod) and then rotating the
rod introducer (MS1-A274).
TM
Entry of the LUMIS percutaneous rod
(MS1-R6xxxT/MS1-R6xxxCT)
additional Note : A small additional incision may be necessary to be able to
incision
insert the rod.
To release the rod, unscrew the locking screw with the T30 shaft (MS1-A411) preassembled with the
dual purpose handle (U1-A622).
GMS2-ST_04GB See package insert for labeling limitation 36
