With the reversed rod introducer :




                                                                  MS1-A275
















 Step1   Step2






 MS1-A214









                                                                            MS1-A214













 To avoid having to make an additional skin incision, it is necessary to use the enlarged


 screw extender (MS1-A214) in combination with the reversed rod introducer.



 Lower the rod into the enlarged screw extender on the end of the construct, and rotate


 the rod into the screw heads.





















 GMS2-ST_04GB   See package insert for labeling limitation                                                 38
