With the reversed rod introducer :




                                                                                                                                                                                         MS1-A275
















                     Step1                                                                                                 Step2






                                                                                      MS1-A214









                                                                                                                                                                                                   MS1-A214













                    To avoid having to make an additional skin incision, it is necessary to use the enlarged


                    screw extender (MS1-A214) in combination with the reversed rod introducer.



                    Lower the rod into the enlarged screw extender on the end of the construct, and rotate


                    the rod into the screw heads.





















          GMS2-ST_04GB                                                                           See package insert for labeling limitation                                                                                       38
