Ava Compact Dome Camera

The AI-powered, cloud-native Avigilon Ava Compact Dome camera is discreet, robust, and easy to install and manage,
providing crystal clear visibility indoors to help ensure safety and security.

Specifications

MODEL NAME AVIGILON AVA COMPACT DOME CAMERA
COMPACTDOME-W-5MP-30
Part Number COMPACTDOME-W-5MP-60 COMPACTDOME-W
COMPACTDOME-W-5MP-120
On-board Storage 30, 60, or 120 days None. Cloud Connector required.
Resolution (MP) 5 MP
Image Sensor Size Format 1/2.7”
IR Night Vision Automatic Night Mode, IR-cut filter, 10m IR Range, 850 nm IR LED
Minimum Illumination in Color Mode 0.10lux
Max. Resolution and Frame Rate 2688x1944@30fps
Dynamic Range Multi-exposure line-based HDR

Environmental Operating: 0°C to +40°C
Storage: -40°C to +60°C
Security Trusted Platform Module, Factory-installed certificates, No default passwords,
Mandatory access authentication, HTTPS/TLS encryption
Dimensions: 107x107x64mm
Physical Characteristics
Weight: 280g
LENS (REMOTE ZOOM AND FOCUS)
3.2mm, Horizontal Field of View 102°
ƒ/1.3, Fixed
focus Vertical Angle of View 71°

Audio, power & networking
Key features
Audio Microphone
Easy installation,
configuration, and Cloud-native deployment Power Source PoE 802.3af
management USB-C, installation only
AI video analytics for Audio analytics and Typical: 5W
loitering, anomalies acoustic sensor Power Consumption Max: 8W
and more
IPv4, HTTPS, TLS, DNS, mDNS, DNS-SD, NTP,
On-board storage¹ Networking Protocols RTSP, RTP, RTCP, ICMP, DHCP, ARP
5 MP Image Sensor and processing Streaming: RTP/UDP, RTP/RTSP/HTTPS/TCP
802.3ab 10/100/1000 Gigabit Ethernet
Connection
USB-C for preview and setup

1 Available on most models
