Page 53 - February 2018-Turolight
P. 53
LED Wrap Around
DL-WA
Ordering Information Example: DL-WA1/4F/40W/40
Family Name Fixture Type Size Wattage CCT Options
DL (Deltalum) WA1(Wrap Around 1) 4F (4’) 40W 40 (4000K)
50 (5000K)
Product Specification
Ordering DLC Model Number Wattage Input Voltage Hour Rating Beam Angle Initial Lumens CCT (K) CRI Damp M.O.L Case QTY.
Code (W) (V) (lumen) Location (inch)
3665124 Yes DL-WA1/4F/40W/40 40 120-277V 50,000 120 4,000 4000K >80 Yes 48 4
3665125 Yes DL-WA1/4F/40W/50 40 120-277V 50,000 120 4,000 5000K >80 Yes 48 4
page 2 of 2, A18 Tel: (416) 736-0447 • Toll Free: 1 (877) 736-0447 • Fax: (416) 736-4890 • Email: info@turolight.com • Website: www.turolight.com
