P. 56

LED FIXTURE


                                                                                                   4F2L
                  DL Series




          LED Connect Strip                                                      2F1L


           DL-CS
           Linear 2’ or 4’ LED strip light




          Features & Benefits
           CUL listed, DLC                                         L70 @ 50,000 HRS
           Familiar surface strip design in 2’ and 4’ length, low profile  White metal housing construction, PC Opal Lens
           Multiple lumen options to suite most applications       0-10V dimmable
           Integral-LED luminaire (no lamps required)              Damp location rated
           Strips are linkable either with connector supplied or by optional connecting
           cables







          Warranty                                                Applications
           5-year limited warranty in commercial use from the date of purchase  Cove Lighting, Utility Rooms, Corridors, Work Shops, Garage, Stock Rooms etc.
           Operating temperature range between -20˚C and +40˚C




          Dimensional drawing

            2’ (24”)               L
               2L                                       W               H

               1L                                       W               H



            4’ (48”)                                   L
               2L                                                                        W               H

               1L                                                                        W               H

                                   L        W         H
                         2F1L      24”     1 3/4”   2 3/16”
                         2F2L      24”     3 9/16”  2 3/16”
                         4F1L      48”     1 3/4”   2 3/16”
                         4F2L      484”    3 9/16”  2 3/16”



          page 1 of 2, A18                                Tel: (416) 736-0447 • Toll Free: 1 (877) 736-0447 • Fax: (416) 736-4890 • Email: info@turolight.com • Website: www.turolight.com
