Page 54 - February 2018-Turolight
P. 54
4’ (48”)
LED FIXTURE
DL Series
8’ (96”)
LED Vapor Tight
DL-VT
Linear 4’ or 8’ IP65 rated luminaire, suitable for wet locations.
Features & Benefits
CUL listed, DLC premium LED module with LG / Everlight chip
High impact polycarbonate grey housing, IK08 130 lm/W
High impact diffuser polycarbonate IK08, opal, 82% transmission Stainless steel fastening clips
Stainless steel mounting brackcets included Optional microwave motion sensor
c/w PG13.5 threaded cable gland
0-10V Dimming / Philips / Meanwell LED Driver
Warranty Applications
5-year limited warranty in commercial use from the date of purchase Indoor or outdoor, suitable for waterpoof, dustpoof and moistureproof needs*
Parking garage, Truck shop, Stairwell, Breeze way, Corridor, Car wash etc.
Operating temperature range between -20˚C and +40˚C
* Special enviroment use, please contact your sales representative.
Dimensional drawing
4’ (48”)
L
W
H
8’ (96”)
L W
H
L W H
4’ (48”) 48.0” 4.9” 4.1”
8’ (96”) 99.0” 6.3” 4.3”
page 1 of 2, A18 Tel: (416) 736-0447 • Toll Free: 1 (877) 736-0447 • Fax: (416) 736-4890 • Email: info@turolight.com • Website: www.turolight.com
