AMD AM4 Power Sequence and Timing

PCIE_RST#
APU_PWOK
PWR_GOOD
APU_VDD_RUN_PG

APU_VDD_RUN
APU_VDD_RUN_EN
VDDIO_PWRGD
PM_2V5
2.5V_PROM
A_VDDP
VDDP
A_VDD1V8 / A_VDDPS5
+1.8V /+1.05V

+12V
+5V/+3.3V
PS_ON
SLP_S3#
VPP_PWRGD VPP_MEM_PG
VPP_MEM VPP_MEM
VTT_MEM VDDIO_MEM
VDDIO_MEM_S3

SLP_S5#
PWR_BTN#
RSMRST#
PM_1V05_PWRGD
VDDP_PWRGD
PM_1V05SUS
1.05V_PROM_S5
VDDP_S5 A_VDDPS5
+1.5V_ALW
A_VDD18S5
VCC_18_S5
3VDUAL
+3.3V_ALW
5VDUAL
+5V_ALW
+3.3VSB 3VDUAL_IO
+5VSB
