BIG LIGHT 2017 ∙ INDOOR RECESSED LIGHTS 041

MINI TRIA HOUSING MINI TRIA MINI TRIA
IC, Square Light Engine, Square Light Engine, Square
• ICAT Housing, for insulated ceilings and air-tight • 840-1060 lumens • 840-1060 lumens
installations • Petite 2" aperture • Petite 2" aperture
• The 0-10V dimming option is 120-277V • Available in additional color temperatures and • Available in additional color temperatures and
voltages; contact customer service voltages; contact customer service
Lamp details Lamp details
LED 1x 18W CRI>90 LED 1x 18W CRI>90

Product details Product details Product details
120V 120V 120V
Material: Aluminum Total consumption: 18W Total consumption: 18W
L: 11.25 in. W: 10.75 in. H: 7.25 in. Material: Aluminum Material: Aluminum
L: 2.75 in. W: 2.75 in. H: 3.85 in. L: 2.75 in. W: 2.75 in. H: 3.85 in.
dimmable: L, C, Triac dimmable: L, C, Triac

3.16 0.67 50000 0.67 50000

Series available in other variants Series available in other variants Series available in other variants
Product family MiniTria see page 014–019. Product family MiniTria see page 014–019. Product family MiniTria see page 014–019.
Note Note
Use with IC Housing ELV Dimming (781291U) or Use with IC Housing ELV Dimming (781291U) or
IC Housing 0-10V Dimming (781311U). IC Housing 0-10V Dimming (781311U).
2.4” 2.4”
7.25”
3.85” 3.85”
11.25”

10.75” 2.75” 2.75”

Variant Item No. Variant Item No.
3000K 840-1060lm 15° 3000K 840-1060lm 15°
White 705134A Dark Blue 705224A
Gold 705194A Black 705164A
3000K 840-1060lm 25° 3000K 840-1060lm 25°
White 705144A Dark Blue 705234A
Gold 705204A Black 705174A
Variant Item No. 3000K 840-1060lm 40° 3000K 840-1060lm 40°
IC Housing, square, ELV dimming 781291U White 705154A Dark Blue 705244A
IC Housing, square, 0-10V dimming 781311U Gold 705214A Black 705184A
