Airframe UAV’s Configuration
1. Fixed-wing
2. Rotary-wing.
Figure 1 Rotarywing(up)danfixed-wing(down)
Methodology
The Creating and Developing Airframe Unmanned Aerial Vehicle will be explaining Figure 2.
Figure 2.1 Diagram Blocks System
Table 1 Harrdware Components
No. Materials Unit
1 Arduino Mega 1
2 Servo 4
3 Motor Brushless& 4
ESC
4 Remote Control 1
5 Gy 87 1
6 GPS 1
7 Humidity sensor 1
8 Baterai 1
9 Telemetry 1
10 Module Power 1
Hardware System.
Developing airframe likes aircraft without crew and passenger to catch up video, audio and photograph into Arduino
Microcontroller. They have some components and tools supporting.
