Several observations, from [FEIT15], may be helpful in this regard. First, we note that with respect
to changes in values, the GM gives equal weight to all of the values in the data set. For example,

suppose the set of data values to be averaged includes a few large values and more small values.
Here, the AM is dominated by the large values. A change of 10% in the largest value will have a
noticeable effect, while a change in the smallest value by the same factor will have a negligible
effect. In contrast, a change in value by 10% of any of the data values results in the same change
in the GM: 2 n 1.1.

https://www.youtube.com/watch?v=xt07TExQNVg

A second observation is that for the GM of a ratio, the GM of the ratios equals the ratio of the
GMs:

=

Compare this with Equation 2.4. For use with execution times, as opposed to rates, one drawback

of the GM is that it may be non-monotonic relative to the more intuitive AM. In other words,
there may be cases where the AM of one data set is larger than that of another set, but the GM
is smaller.

1. As mentioned, the GM gives consistent results regardless of which system is used as a
reference. Because benchmarking is primarily a comparison analysis, this is an important feature.

2. As documented in [MCMA93], and confirmed in subsequent analyses by SPEC analysts
[MASH04], the GM is less biased by outliers than the HM or AM.

3. [MASH04] demonstrates that distributions of performance ratios are better modeled by
lognormal distributions than by normal ones, because of the generally skewed distribution of the
normalized numbers. This is confirmed in [CITR06]. And, as shown in Equation (2.5), the GM can

be described as the back-transformed average of a lognormal distribution.

2.15.2 Benchmarks And Spec
Benchmark Principles Measures such as MIPS and MFLOPS have proven inadequate to evaluating
the performance of processors. Because of differences in instruction sets, the instruction
execution rate is not a valid means of comparing the performance of different architectures.

https://www.youtube.com/watch?v=QFV036TtLTc

1. It is written in a high-level language, making it portable across different machines.

2. It is representative of a particular kind of programming domain or paradigm, such as systems

programming, numerical programming, or commercial programming.
