P. 621
MECHANICAL DRAWING LIST
M 0 0
M 0 1 FIRE SYSTEM (GROUND) M 1 3 MECHANICAL SCHEDULE
M 0 2 FIRE SYSTEM (FIRST) M 1 4 MECHANICAL DETALIS
M 0 3 FIRE SYSTEM (ROOF)
M 0 4 GROUND AIR CONDITION
M 0 5 1ST FLOOR AIR CONDITION
M 0 6 ROOF FLOORAIR CONDITION
TOP ROOF
M 0 7 OUTDOOR UNIT
M 0 8 TOP ROOF
OUTDOOR UNIT
M 0 9 COOLING CAPACITY
M 1 0 GROUND EXAUST FAN
MECHANICAL DRAWING LIST
M 1 1 1ST FLOOR EXAUST FAN
ROOF FLOOR EXAUST FAN A 3
M 1 2
E 0 0 0
