P. 537
Terminal Buss Bar QRP57-801 Extreme LCD Digital Tachometer
Glass-fi lled red nylon Buss QRP611-7010
Bar with 12 connection Digital tachometer's compact 2-5/8" diameter
terminals, each able to allows it to be easily mounted or installed into
handle up to 15 amps any Extreme gauge panel. Tachometer may
continuously. Unit features 1/4" be used simply as an RPM indicator, or as a
stainless steel terminal post and 12/ shift light. RPM settings are adjusted by simply
#8-32 stainless steel attaching screws.
touching the lens with a fi nger. Unit also includes a recall feature,
which displays the highest RPM attained at the end of the race.
Sleeved Race Spark Plug Wire
Premium spark plug wire of-
fers quick energy transfer, less Memory Tachometers
than 40 Ohms/ft. of resistance, American-made, 10,000 RPM tachometers
high EMI and RFI suppression. are affordable and accurate. In-dash mount
Wires combine a Kevlar core, tachs have silver dial faces, bright red point-
nickel-copper alloy wound ers, black bezels and advanced LED lighting.
conductor, fi berglass insula- Recall feature displays the highest RPM
tion and two full layers of attained during the last race.
silicone. Fitted with posi-snap Part No. Description
terminals and high temperature QRP611-6001 Tachometer With Memory, 5" Dia.
silicone boots, wire is offered in red QRP611-6002 Tachometer With Remote Recall, 3-3/8" Dia.
or black. Replacement coil wires may be
purchased separately. Extreme Gauges
Red Black Gauges were designed with the serious
Description Part No. Part No. racer in mind. Lightweight, 2-5/8" diameter
SB Chevy Wire Set, 24” Coil Wire QRP40-100 QRP40-300 gauges feature white dial faces with bright
SB Chevy Wire Set, Less Coil Wire QRP40-150 QRP40-350 red pointers and built-in LED back lighting.
Gauges may be set-up for the back-lighting
Digital Tire Pressure Gauge to change colors automatically if a problem
QRP56-085 arises by simply purchasing the necessary senders. Each gauge
The most accurate tire pressure gauge is sold complete with LED lighting.
currently offered by QuickCar is calibrated Part No. Description
to .5% accuracy. Gauge, which reads in QRP611-7000 Fuel Pressure, 0-15 PSI
Oil Pressure, 0-100 PSI
PSI, Bar, KG or KPA, incorporates an easy- QRP611-7003 Water Temperature, 100°-280°F
QRP611-7006
to-read backlit screen, auto shut-off for QRP611-7007 Voltmeter, 8-18 Volts
extended battery life, and a premium, 14" QRP611-7009 Oil Temperature, 100°-320°F
long whip hose with angled air chuck. QRP611-7012 Transmission Temperature, 100°-320°F
Pressure And Temperature Switches
QRP61-730 Fuel Pressure Switch, 1/8" NPT, Activates Light At 4 PSI
QRP61-733 Oil Pressure Switch, 1/8" NPT, Activates Light At 30 PSI
Fuel Pressure Isolator QRP61-300 QRP61-735 Oil Pressure Switch, 1/8" NPT, Activates Light At 20 PSI
Specialized, billet aluminum isolator eliminates QRP61-740 Water Temperature Switch, 1/2" NPT, Activates Light At 235°F
the hazards associated with driver’s compart- QRP61-748 Water Temperature Switch, 3/8" NPT, Activates Light At 235°F
QRP61-750
Oil Temperature Switch, 1/2" NPT, Activates Light At 280°F
ment mounted fuel pressure gauges. Typically
mounted to the engine side fi rewall, isolator is
plumbed with the pressure source on the inlet Performance Gauges
side and an anti-freeze/water mix on Affordable, illuminated 2-5/8" diameter
the outlet, which connects to the gauge. gauges have silver dial faces with bright red
Compatible with gasoline, alcohol or pointers.
methanol fuels, isolator is capable of Part No. Description
monitoring pressures up to 80 PSI, and is sold complete with QRP611-6000 Fuel Pressure, 0-15 PSI
-4AN adapter fi ttings, mounting bracket and necessary hardware. QRP611-6003 Oil Pressure, 0-100 PSI
QRP611-6006 Water Temperature, 140°-280°F
QRP611-6009 Oil Temperature, 140°-340°F
Mini Fuel Pressure Gauges
Ideally mounted to fuel pressure regulators
or fuel logs, mini 1-1/2” diameter fuel pres-
sure gauges are liquid-fi lled to ease read-
ability.
Part No. Description
QRP611-9015 0-15 PSI
QRP611-90100 0-100 PSI
