MTT4NF5001250F
Titanium Bolts, Studs And Nuts
Fasteners are made with aircraft grade titanium alloy. Mettec bolts have forged heads for superior strength. The threads are then rolled to
produce greater fatigue strength and reduce galling. Bolts exceed minimum ultimate tensile strength of 120,000 psi. All fasteners are sold
each unless specified.
1/2"-20 With
Length 1/4"-20 1/4"-28 5/16"-24 3/8"-24 3/8"-16 7/16"-20 1/2"-20 9/16" Hex Head
1/4" — — — — — — — MTT4NF5001250F*
1/4" — — — — — — — MTT4NF5001250FS**
1/2" — MTTT4NF02500500 — — — — — —
5/8" MTTT4NC02500625 MTTT4NF02500625 — — — — — —
3/4" — MTTT4NF02500750 — — — — — —
7/8" — — — MTTT4NF03750875 — — — —
1" — — MTTT6NF03121000 MTTT6NF03751000 MTTT4NC03751000 — — —
1-1/4" — — — MTTT4NF03751250 MTTT4NC3751250F MTTT4NF04371250 MTTT4NF05001250 —
1-3/8" — — — — — — — MTT4NF5001375FS
1-1/2" — — — MTTT6NF03751500 MTTT4NC3751500F MTTT4NF04371500 MTTT4NF05001500 MTT4NF5001500F
1-3/4" — — — — — — MTTT4NF05001750 MTT4NF5001750F
1-5/8" — — — — — — — MTT4NF5001625F
1-7/8" — — — — — — — MTT4NF5001875F
2" — — — MTTT6NF03752000 — — MTTT4NF05002000 MTT4NF5002000F
2-1/4" — — — — — — — MTT4NF5002250F
2-1/2" — — — MTTT6NF03752500 — — MTTT4NF05002500 MTT4NF5002500F
2-3/4" — — — — — — MTTT4NF05002750 MTT4NF5002750F
3" — — — — — — MTTT4NF05003000 —
3-1/2" — — — — — — MTTT4NF05003500 MTT4NF5003500F
3-3/4" — — — — — — — MTT4NF5003750F
4-1/2" — — — — — — — MTT4NF5004500F
Note: Fasteners with “F” suffix have a flange head. * 1-1/4" With 1" Thread Length ** 1-1/4" With 1/2" Thread Length
Titanium Stud, Nut and Bolt Kits MTTKT537 Triple XXX And
Mettec products are constructed Maxim Chassis Bolt Kit
with aircraft grade titanium alloy MTTKIT500HFMAXR1
which is 37% lighter than steel.
Bolts and studs feature threads that 30 piece, 1/2" titanium bolt and nut kit
are rolled to produce greater fatigue, with 9/16" hex heads. 47% lighter than
strength and reduce galling. In ad- comparable steel products with no
dition, bolts have forged heads for chance of rust or corrosion.
superior strength. Made in USA.
Part No. Description
Titanium Radius Rod One Nut Stud Kit For Through Hole Bung
MTTKT537
In Frame, Kit Includes Six Studs And 12 Steel Nylock Nuts
Titanium Radius Rod To Frame 1/2 Bolt Kit, Contents Include Jacobs Ladder Quick Pin Kit
MTTKT538
Six 1/2"-20 x 2-3/4" Hex Head Bolts And 6 Steel Nylock Nuts MTTKT520
Titanium Drag Link And Tie Rod Kit,
MTTKT502
Kit Includes Four Studs And Eight Steel Nylock Nuts Titanium kit with 1/2" pins for bird cage
Titanium Shock Bolt Kit For Through Bung In Frame, heims. Pins are drilled for weight reduc-
MTTKT503
Kit Contains Eight Studs And 16 - 1/2"-20 Steel Nylock Nuts tion. Three pins per kit.
Titanium Shock Pin Stud Kit For Threaded Bung In Frame,
MTTKT503C
Kit Contains Eight Studs And 16 - 1/2" x 20 Steel Nylock Nuts
Titanium Shock Pin Stud Kit For 1/2"Threaded Frames, Kit Miscellaneous Bolts, Single Stud And Nuts
MTTKT503S
Contains 10 1/2"-20 x 7/8" Studs And 10 Steel Nylock Nuts
MTTKT530 Titanium Fuel Tank Top Plate Bolt Kit MTTTD502
Titanium Nerf And Bumper Bolt Kit, Kit Contains 12 - 3/16" x MTTTD503
MTTKT531
1-1/2" Hex Head Bolts And 12 Steel Nylock Nuts
Titanium Front Hub 12 Point Star Bolt And Hex Flange Nut Kit, Part No. Description
MTTKT533 Kit Contains Five 3/8"-16 x 1-3/8" Bolts And MTTT12NC375125B Wide 5 Front Wheel Studs,
Five 3/8" Titanium Nuts 3/8" x 16 x 1-1/4" Star Hd. Bullet Nose
Titanium Bead Lock Bolt Kit, Kit Contains MTTNUTHF375-16 Titanium Hex Flange Wheel Nut 3/8" x 16
MTTKT540B
16- 5/16-18 x 1" Bolts And 16 .032" Steel Washers MTTSTUD375X1200 Single Header Stud, 3/8" Dia. x 1.125" L.
Titanium Shock Stud Kit For 1/2"-20 Threaded Frame Bungs, MTTSTUD375X1500 Distributor Stud, 3/8" Dia. x 1.500" L.
MTTKT539
Kit Contains Six Studs and Six Steel Nylock Nuts MTTSTUD375x1750 Single Torque Tube Stud, 3/8" x 1-3/4"
Titanium U-Joint Bolt Kit, MTTSTUD375x2000 Single Torque Tube Stud, 3/8" x 2"
MTTKT541
Four 12 Point 7/16"-20 x 7/8" Flanged Head Bolts MTTTD502 Titanium Drag Link And Tie Rod, One Nut/ Single Stud
Titanium Header Stud And Nut Kit, MTTTD503 Titanium Rear Shock Lower Arm, One Nut/ Single Stud
MTTKT534 Kit Contains 14- 3/8" Studs With 5/32" Hex Key Broached MTTSD502 Steel Drag Link And Tie Rod, One Nut/ Single Stud
In One End And 14 Moly Coated Hex Flange Nuts MTTSD503 Steel Rear Shock Lower Arm, One Nut/ Single Stud
MTTT4FNF5002000 Front Steer Arm Bolt, 1/2" x 2" Flush Head (Sprint)
MTTT4FNF5001000 Front Brake Rotor Bolt, 1/2" x 1" Flush Head
Moly Paste 1/2 Oz. MTTMOLY.5OZ
Paste reduces galling and seizing of titanium threads.
