Page 327 - 2018 Racecar Engineering Open Wheel Parts and Accessories Catalog

Replacement Gauge Panel Components Quick-Lite Warning Light Kits
A variety of replacement bulbs, pilot lights, pressure and tempera- Warning light kits immediately alert the driver of engine problems.
ture switches are available for use with popular QuickCar gauge Each kit is sold complete with warning light, sending switch and
panels. wiring.
QRP61-733
Oil Pressure Kit QRP61-711
QRP61-691 Kit includes red warning light, pressure
Part No. Description sending unit that actuates the warning light
QRP61-691 Red LED Bulbs For Standard QuickCar Gauges, Pair if oil pressure drops below 20 PSI, brass
QRP61-692 Blue LED Bulbs For Standard QuickCar Gauges, Pair
QRP61-693 Amber LED Bulbs For Standard QuickCar Gauges, Pair inline tee for oil pressure line, and pre-terminated wiring.
QRP61-694 Green LED Bulbs For Standard QuickCar Gauges, Pair
QRP61-698 White LED Bulbs For Standard QuickCar Gauges, 4-Pack Water Temperature Kit QRP61-712
QRP61-699 White LED Bulbs For Standard QuickCar Gauges, Each Kit includes blue warning light, tempera-
QRP61-701 Red Warning Light, 3/4" Dia.
QRP61-702 Blue Warning Light, 3/4" Dia. ture sending unit that actuates the warning
QRP61-704 Yellow Warning Light, 3/4" Dia. light if water temperature exceeds 235°F,
QRP61-706 4-Pc. Warning Light Kit, Includes (1) Red, (1) Blue, (1) Amber And (1) Green and pre-terminated wiring.
QRP61-709 Green Warning Light, 3/4" Dia.
QRP61-730 Fuel Pressure Switch, 1/8" NPT, Activates Warning Light @ 4 PSI Oil Temperature Kit QRP61-714
QRP61-733 Oil Pressure Switch, 1/8" NPT, Activates Warning Light @ 30 PSI Kit includes amber warning light, tem-
QRP61-735 Oil Pressure Switch, 1/8" NPT, Activates Warning Light @ 20 PSI
QRP61-740 Water Temperature Switch, 1/2" NPT, Activates Warning Light @ 235°F perature sending unit that actuates the
QRP61-748 Water Temperature Switch, 3/8" NPT, Activates Warning Light @ 235°F warning light if oil temperature exceeds
QRP61-750 Oil Temperature Switch, 1/2" NPT, Activates Warning Light @ 280°F 280° F., and pre-terminated wiring.
Temperature And Pressure Adapters
Required to connect mechanical water or oil temperature, and Fuel Pressure Kit QRP61-719
pressure gauges to engine. Kit includes green warning light, pressure
sending unit that actuates the warning light
if fuel pressure drops below 4 PSI, and pre-termi-
QRP61-724 QRP611-903 nated wiring.
Part No. Description
QRP61-724 1/8" NPT Female To -4AN Male, Gauge Adapter Water Pressure Kit QRP61-713
QRP61-725 1/8" NPT Male To -4AN Male, Oil/Fuel Pressure Adapter Kit provides instant notice in the event of a
QRP611-900 1/2" NPT Brass Temperature Adapter blown hose, radiator or head gasket problem.
QRP611-901 1/2" NPT Aluminum Temperature Adapter
QRP611-902 3/8" NPT Aluminum Temperature Adapter Sold complete with blue warning light, pres-
3/8" NPT Extended Aluminum Temperature Adapter, sure sending unit that actuates the warning
QRP611-903 Required Where Standard Adapter Contacts Manifold light if water pressure drops below 4 PSI, and pre-terminated wiring.
Or Cylinder Head Prior To Tightening
Quick-Lite 9V
Fuel Pressure Isolator QRP61-300 Oil Pressure Warning Kits
Isolator eliminates the hazards associated with driver’s
Part No. Description
compartment mounted fuel pressure gauges. Typically 9V Oil Pressure Warning,
mounted to the engine side firewall, isolator is compat- QRP61-717 Includes Brass Tee Fitting
ible with gasoline, alcohol or methanol fuels. Manufac- 9V Pro Oil Pressure Warning,
tured from black anodized, 6061-T6 billet alumi- QRP61-718 Includes Aluminum Tee Fitting QRP61-717
num, isolator is capable of monitoring pressures
up to 80 PSI and is sold complete with -4AN adapters
and mounting hardware. Water Pressure Kit With
2-1/16" Dia. Gauge QRP61-716
Keep track of spikes or loss of cooling system
Oil Temperature Manifold QRP61-755 pressure.Kit is similar to the QRP61-713 kit with the
Installed in-line to allow monitoring engine oil addition of a 2-1/16" dia., 0-35 PSI water pres-
temperature, manifold is constructed from rigid, sure gauge.
billet aluminum. Manifold includes -10AN O-ring
Part No. Description
boss inlet and outlet ports, and a 3/8" female NPT Quick-Lite Warning Light Kit Replacement Components
port for an oil temperature probe.
QRP61-701 Red Warning Light, 3/4" Dia.
QRP61-702 Blue Warning Light, 3/4" Dia.
Firewall Junction Mounting Blocks QRP61-704 Yellow Warning Light, 3/4" Dia.
Designed to add longevity to any pressure QRP61-709 Green Warning Light, 3/4" Dia.
sensor or transducer, black anodized aluminum QRP61-730 Fuel Pressure Switch, 1/8" NPT, 4 PSI
mounting blocks allow the sensor to be mounted away from the heat QRP61-733 Oil Pressure Switch, 1/8" NPT, 30 PSI
and vibration created by the engine. The blocks include 1/8" NPT QRP61-735 Oil Pressure Switch, 1/8" NPT, 20 PSI
female threads with either two or three holes, providing a clean, QRP61-740 Water Temperature Switch, 1/2" NPT, 235°F
remote location to mount all sensors together. QRP61-748 Water Temperature Switch, 3/8" NPT, 235°F
Part No. Description QRP61-750 Oil Temperature Switch, 1/2" NPT, 280°F
QRP63-120 Two Hole Firewall Junction Block
QRP63-130 Three Hole Firewall Junction Block
