Page 325 - 2018 Racecar Engineering Open Wheel Parts and Accessories Catalog

Digital Open Wheel Gauge Panels QRP67-2004 QuickTach LCD Recall Tachometers
Lightweight aluminum panels QuickTach automatically
have digital, 2-1/16" dia. electronic displays the highest RPM at-
oil pressure and water temperature tained from the last race for
gauges with bright blue readout 15 minutes after shut down.
and graduated scale for increased Digital LCD unit is enclosed
readability. Built-in warning lights, in a waterproof aluminum
pre-set with the touch of a finger, case and has an easily
cause the lighting to flash in the event read, 3/4" x 2-3/4" back
of a problem. Weather resistant panels lighted display. Powered by a 9-volt battery. Tach includes mounting
use a 12-volt battery for power, or for brackets.
traditional sprint cars that lack a battery Part No. Description
and require a self-contained panel. Self- QRP611-099 QuickTach, White/Red With Checkered Flag
contained unit uses a compact, 12-volt QRP67-2005 QRP611-100 QuickTach, Black
rechargeable battery for power and includes a double-pole switch
that functions as both a kill switch and as a means of activating the QRP611-098 Wiring Harness For QuickTach
gauge panel. Self-contained panel includes a battery and charger.
Part No. Description Extreme Gauge Panels
QRP67-2004 Used With 12-Volt Battery, 6-3/4" W x 3" H With LED Digital Tachometer
QRP67-2005 Self-Contained With Battery, 6-3/4" W x 4-1/16" H QRP61-7042
2-1/16" Digital Gauges
May also be purchased separately. Senders or transducers are not
included.

Gauge panels feature the Extreme gauges combined with the ad-
dition of the Extreme LED Digital Tachometer, which may be used
as an RPM indicator or shift light that also includes a recall feature.
RPM settings are adjusted by simply touching the lens with a finger.
QRP67-000 QRP67-006 QRP67-007 QRP67-009
Panels also include lightweight, 2-5/8" dia. white face mechanical
Part Number Description
gauges with bright red pointers mounted in gloss black finished
QRP67-000 Fuel Pressure, 0-15 PSI panels. Fully assembled and pre-wired, panels are complete with
QRP67-003 Oil Pressure, 0-100 PSI necessary senders. No external warning lights are needed; gauges
QRP67-005 Fuel Pressure, 0-100 PSI use LED lights and switch automatically from white to designated
QRP67-006 Water Temperature, 100°-280° F color when a problem arises. Gauges are mounted using vibration
QRP67-007 Voltmeter, 8-18 Volts absorbing grommets for added durability. Panels can be assembled
QRP67-008 Water Pressure, 0-100 PSI with any combination of gauges by special order.
QRP67-009 Oil Temperature, 100°-320° F Part No. Description
2-1 Gauge Panel,
QRP61-7031
Replacement Senders Oil Pressure, Water Temperature And Digital Tachometer
3-1 Gauge Panel,
Part No. Description QRP61-7041 Oil Pressure, Water Temperature, Oil Temperature
QRP63-220
Water Temp/Trans Temp And Digital Tachometer
QRP63-220
Sender 3-1 Gauge Panel,
Oil Pressure/Water Pressure QRP61-7042 Oil Pressure, Water Temperature, Fuel Pressure
QRP63-230
Sender, 0-100PSI And Digital Tachometer
Fuel Pressure Sender, 4-1 Gauge Panel,
QRP63-240
0-15 PSI QRP61-7051 Oil Pressure, Water Temperature, Oil Temperature,
Fuel Pressure And Digital Tachometer
Extreme LED Digital Tachometer
QRP611-7010 Sprint Gauges
Digital tachometer's compact, 2-5/8" diam-
eter allows it to be installed into any Extreme Lightweight 2-5/8" diameter oil
pressure and water temperature
gauge panel. Tachometer may be used as
simply an RPM indicator, or as a shift light. gauges include shockproof, rubber
mounting grommets and do not
RPM settings are adjusted by simply touch-
ing the lens with a finger. Unit also includes a need mounting hardware. QRP611-6004 QRP611-6005
recall feature, which displays the highest RPM Part No. Description
attained at the end of the race. QRP611-6004 Oil Pressure, 0-100 PSI
QRP611-6005 Water Temperature, 140°-280°F

324
