Page 326 - 2018 Racecar Engineering Open Wheel Parts and Accessories Catalog

Deluxe Sprint Panels Extreme Series Gauge Panels
Made in the USA
and designed with the
serious racer in mind,
Extreme series gauges
feature built-in LED
QRP61-6004 QRP61-7004 QRP61-0604
lights that illuminate in
the event of a problem. QRP61-7021
Under normal operating
conditions, the gauges
are illuminated with LED
white lights. If a prob-
QRP61-6006 QRP61-0606 QRP61-0705
Very strong and dependable gauge panels are outfitted with light- lem arises, it changes
to a warning color,
Warning lights illuminated
weight, sealed gauges and available in two styles. The Deluxe panel quickly alerting the driver. Lightweight, 2-5/8" diameter gauges are
has a self-contained oil pressure warning system; the Pro panel fas- mounted in the panel using a rubber grommet for reduced vibra-
tens to dash from engine bay and stays with engine when it is pulled. tions. Warning levels are printed in red so a quick glance is all that
Mounting hardware not included.
is needed. Panels are pre-wired with QuickCar 14 gauge wire, extra
Part No. Description thick, gold plated connectors, and include senders.
QRP61-0604 Pro Sprint Panel, Ultra Nite Part No. Description
QRP61-0605 Deluxe Sprint Panel, Ultra Nite 2-Gauge Panel,
QRP61-0606 Sprint Panel, Ultra Nite Vertical Mount QRP61-7001 Oil Pressure And Water Temperature
QRP61-0704 Pro Sprint Panel, Ultra Nite, Carbon Fiber 3-Gauge Panel,
QRP61-7011
QRP61-0705 Deluxe Sprint Panel, Ultra Nite, Carbon Fiber Oil Pressure, Water Temperature And Oil Temperature
QRP61-6004 Deluxe Sprint Panel, With Warning Light QRP61-7012 3-Gauge Panel,
QRP61-6005 Pro Sprint Panel, With Warning Light Oil Pressure, Water Temperature And Fuel Pressure
QRP61-6006 Sprint Panel, Vertical Mount 3-Gauge Panel,
QRP61-7017
QRP61-7005 Deluxe Sprint Panel, With Warning Light, Carbon Fiber Oil Pressure, Water Temperature And Volt Meter
QRP61-7004 Pro Sprint Panel, Carbon Fiber 4-Gauge Panel,
QRP61-7021 Oil Pressure, Water Temperature,
Oil Temperature And Fuel Pressure
Gauge Ring Shock Guard QRP61-727
Rubber offset gauge grommet isolates the gauge
from engine vibrations, while also providing a tight, Gauge Panels
lightweight solution to holding the gauge in place. QuickCar gauge panels offer racers a
Grommet moves gauge 3/4" towards the driver to revolutionary view of their large, 2-5/8” di-
give more room behind the gauge. Designed for ameter gauges. Large graphics, bright red
2-5/8" gauges, mounting panel will need a 2-3/4" hole for correct pointers, illuminated silver dial faces, 12:00
tolerances. markings and color-coded printing provide
easy separation of gauges and warning
lights. All panels are completely wired and
Individual Extreme Gauges ready to install. Extra thick connectors and
Extreme gauges are also offered separately. Gauges are 2-5/8" high temp 14 gauge cable connects warn-
diameter, have white dial faces and are complete with LED lighting ing and illumination lights. Choose from
and saddle bracket. checkered flag or black gauge panels.
Checkered Flag Black
Description Part No. Part No.
2-Gauge Panel,
Oil Press. And Water Temp. QRP61-6001 QRP61-6701
3-Gauge Panel, QRP61-6011 QRP61-6711
Oil Press., Water Temp. And Oil Temp.
QRP611-7000 QRP611-7003 QRP611-7007 QRP611-7012 3-Gauge Panel, QRP61-6012 QRP61-6712
Oil Press., Water Temp. And Fuel Press.
Part No. Description
4-Gauge Panel,
QRP611-7000 Fuel Pressure, 0-15 PSI
Oil Press., Water Temp., QRP61-6021 QRP61-6721
QRP611-7003 Oil Pressure, 0-100 PSI Oil Temp. And Fuel Press.
QRP611-7006 Water Temperature, 140°-280°F
QRP611-7007 Voltmeter, 8-18V Individual Gauges
QRP611-7009 Oil Temperature, 100°-320°F
Affordable, illuminated 2-5/8"gauges have
QRP611-7012 Transmission Temperature, 100°-320°F
silver dial faces with bright red pointers.
Part No. Description
QRP611-6000 Fuel Pressure, 0-15 PSI
QRP611-6003 Oil Pressure, 0-100 PSI
QRP611-6006 Water Temperature, 140°-280°F. QRP611-6006
QRP611-6007 Voltmeter, 8-18 Volts
QRP611-6009 Oil Temperature, 140°-280°F.

325
