Page 106 - 2019 Allstar Performance Parts and Equipment Catalog

FASTENERS Step Drill Sets Cleco Pin Fastener Kits NEW!

Cleco pins are reusable and
Drill multiple size holes with one bit.
easily make a temporary
Drill sheet metal and aluminum without
connection between pieces
deforming or distorting. Bits start on
contact, deburr, and chamfer while
ting. Pins will work with
drilling, and do not require a center punch. Titanium
thicknesses up to 1/4". Kits
nitride coated high speed steel. 1/4" shank. ALL11041 of sheet metal during fit-
include pliers and 10 pins.
Drill Bit Sizes
ALL11040 (3-Piece Set) ALL18221 ..... Kit With 1/8" Pins
ALL18225 ..... Kit With 3/16" Pins
Six Step 3/16", 1/4", 5/16", 3/8", 7/16", 1/2"
Nine Step 1/4", 5/16", 3/8", 7/16", 1/2", 9/16", 5/8", 11/16", 3/4"
1/8", 5/32", 3/16", 7/32", 1/4", 9/32", 5/16", 11/32",
Thirteen Step
3/8", 13/32", 7/16", 15/32", 1/2"
ALL11041* (2-Piece Set) Cleco Pliers ALL18220
1/4", 25/64", 35/64", 11/16", 13/16", 7/8", 1", 1-1/8", Unique tool readily installs and
Eleven Step
1-7/32", 1-1/4", 1-3/8" removes Cleco fasteners.
3/16", 1/4", 5/16", 3/8", 7/16", 1/2", 9/16", 5/8",
Twelve Step
11/16", 3/4", 13/16", 7/8"
Air Rivet Gun ALL18210 Pin Type Cleco Fasteners
Durable air riveter speeds up assembly Cleco pins permit quick, easy installation
and quickly fastens steel or aluminum and removal of sheet metal during fitting.
rivets into various materials. Includes Pins work with thicknesses up to 1/4".
nose pieces for 3/32", 1/8", 5/32" and 1/8" Dia. Pins 3/16" Dia. Pins
3/16" rivets. ALL18222 ..... 10-Pack ALL18226 ...... 10-Pack
ALL18223 ..... 25-Pack ALL18227 ...... 25-Pack
ALL18224 ..... 100-Pack ALL18228 ...... 100-Pack

TECH TIP
Drill holes one drill size smaller than the Cleco pin size to
Deluxe Air Rivet Gun assure a tight fit.
ALL18207
Heavy duty air rivet gun can be
used with steel or aluminum Clamp Type Cleco Fastener
rivets from 3/32" to 3/16". ALL18230
Replacement Part A very strong spring clamp to hold pieces
ALL18209 ..... Replacement Jaws together when drilling is not an option. The smooth
for ALL18207 throat prevents paint damage and is 1" deep, with a
maximum clamping range of 1/2".

Hand Rivet Gun
Double Ended Drill Bits
ALL18206
Double ended bits are basically two bits in one.
Includes interchangeable
nosepieces for 3/32", 1/8", 5/32", and 3/16" Convenient bit can be flipped around
dia. rivets. for a fresh sharp bit when drilling
panels for Cleco fasteners or
rivets. Package of 6.
Rivet Gun Adapter For
ALL18201 ..... 1/8"
Cordless Drill ALL18205 ALL18204 ..... 3/16"
Adapter is for reversible cord-
less drills and greatly speeds up
the installation of “blind” rivets commonly used when 13/64" Drill Bits ALL18203
building race car bodies. Tool is a real hand and time saver
compared to hand operated rivet guns, and is designed Drill bit is for flange rivets. High speed steel
for use with all rivets up to 3/16", including 3/16" alu- bits have black oxide finishes and self
minum mandrel rivets, but not recommended for 3/16" centering tips. Flute length:
steel mandrel rivets. Adapter includes nosepieces for 1-3/16", overall length: 2-1/4".
installing 3/32", 1/8", 5/32" and 3/16" rivets. Package of 2.
