ELECTRICAL, GAUGES & IGNITION

Heat Shrink Tubing ALL76160 Nylon Tie Wraps
Place tubing over Secure electrical wiring, gauge
wiring before lines and roll bar padding. 100
attaching terminal per bag. Nylon tie wraps are
end then slide over available in black, natural, red,
crimped terminal blue, yellow and purple nylon.
end, heat to seal and Black Red
strengthen connec- ALL14120 ...... 3-3/4" ALL14126 .......... 7-1/4"
tion. 30-piece kit includes a variety of sizes including 1/16", ALL14122 ...... 6" ALL14127 .......... 14-1/4"
1/8", 3/16", 1/4", 3/8" and 1/2". ALL14123 ...... 7-1/4" Blue
ALL14124 ...... 11-1/4" ALL14128 .......... 7-1/4"
Grommet Set ALL18360 ALL14125 ...... 14-1/4" ALL14129 .......... 14-1/4"
Natural Yellow
Grommets are perfect for protecting ALL14130 ...... 3-3/4" ALL14136 .......... 7-1/4"
wiring and hoses that pass through ALL14132 ...... 6" ALL14137 .......... 14-1/4"
panels up to 1/16" (.062") thick. Kit ALL14133 ...... 7-1/4" Purple
includes 36 grommets (6 of each size: 1/4", ALL14134 ...... 11-1/4" ALL14138 .......... 7-1/4"
5/16", 3/8", 1/2", 5/8" and 11/16"). Grommets ALL14135 ...... 14-1/4" ALL14139 .......... 14-1/4"
are also available in size specific 10-packs.
Part No. Grommet Hole I.D. Panel Hole I.D. Nylon Flush Fit Tie Wraps
ALL18362 3/16" 5/16" Flush fit design ties have the excess
ALL18363 1/4" 3/8" portion of the tie exit in the same
ALL18364 5/16" 7/16"
ALL18365 3/8" 1/2" direction as the original tie, helping
ALL18366 1/2" 5/8" to eliminate the protruding sharp
ALL18367 5/8" 7/8" portion remaining as found in stan-
ALL18368 11/16" 1" dard ties. Package of 100.
ALL14395 ..... 8" Long
Step Drill Sets
ALL14396 ..... 11" Long
Drill multiple size holes with one bit. Drill
sheet metal and aluminum without Nylon Tie Wraps With
deforming or distorting. Bits start on Mounting Holes
contact, deburr and chamfer while
drilling and do not require a center ALL11041 Built-in tab with mounting hole to easily
punch. Titanium nitride coated high speed steel. secure wiring harnesses, hoses or cables
1/4" shank. to a panel with rivets or other fasteners.
Package of 25.
Drill Bit Sizes ALL14390 ..... 8" With #10 Hole
ALL11040 (3-Piece Set) ALL14391 ..... 11" With #10 Hole
Six Step 3/16", 1/4", 5/16", 3/8", 7/16", 1/2" ALL14392 ..... 14" With 1/4" Hole
Nine Step 1/4", 5/16", 3/8", 7/16", 1/2", 9/16", 5/8", 11/16", 3/4"
1/8", 5/32", 3/16", 7/32", 1/4", 9/32", 5/16", 11/32",
Thirteen Step Wire Tie Mounting Bases
3/8", 13/32", 7/16", 15/32", 1/2"
ALL11041* (2-Piece Set) Self-adhesive mounting bases provide a
1/4", 25/64", 35/64", 11/16", 13/16", 7/8", 1", 1-1/8", location for attaching standard wire ties to
Eleven Step
1-7/32", 1-1/4", 1-3/8" secure wiring, cables and hoses. Bases mount to clean flat
3/16", 1/4", 5/16", 3/8", 7/16", 1/2", 9/16", 5/8",
Twelve Step surfaces and accept 75# and smaller wire ties.
11/16", 3/4", 13/16", 7/8"
Package of 10.
Test Light ALL76215 ALL14116 ...... 3/4" x 3/4" Mounting Base
ALL14117 ...... 1-1/8" x 1-1/8" Mounting Base
Quickly diagnose electrical
problems by testing for current
in electrical circuits, relays,
switches or fuses.
Handheld test light
has a 36" lead wire with an insulated clip which fastens
to a common ground and a sharp piercing point to probe
insulated wire or terminals. Indicator light illuminates to
identify powered circuits in 6-12V systems.
