6-Circuit Fuse Block Plunger Style
ALL76180 Brake Light Switch ALL76253
This fuse block is a great power Popular two terminal brake light
distribution starting point for switch found in most vehicles
up to six individual circuits from the 1950’s to today. Ideal
which are protected by ATC/ for most applications, switch is spring loaded to the on
ATO style fuses (sold separately). Block fea- Fuses not position and turns off when contacted by the brake pedal
tures a #10 power supply and six 1/4" male spade included. assembly. Switch has 1/2" threads with jam nuts for easy
terminals for individual circuit connections. Fuse mounting in a bracket, and two .250" blade type terminals.
block is rated at 150 amps at 12 volts, maximum of 25 ELECTRICAL, GAUGES & IGNITION
amps per circuit. Lever Style
Brake Light Switch ALL76250
Fuse Terminals
Switch is commonly used with under-
Terminals attach to cartridge floor mounted brake pedal assemblies
style fuses installed in fuse blocks where switch can contact the brake pedal arm.
to create an additional circuit to ALL76090 ALL76091 Spring loaded switch is designed to return to
power accessories. Terminals slide over the protected leg the open position and has two #10-32 tapped mounting
or “fused” side (side of fuse block that does not have holes, 5/8" on centers. Designed for easy two wire con-
power when fuse is removed) of the fuse. nection, one "+" supply and the other to power brake
Package of 5. lights or a brake light relay. Switch is rated at 4.5 amps and
ALL76090 ..... Mini Fuse Style Terminal features two male bullet terminals.
ALL76091 ..... ATC/ATO Fuse Style Terminal
Pressure Activated
Junction Block ALL76146
Brake Light Switches
Junction block with single 3/8" stud Switch is plumbed into the brake
offers a location to power multiple system and is activated by closing the ALL76252 ALL76251
accessories from one power supply electrical connection with rising brake pressure (60-120
or a common place to locate ground PSI). Designed for easy two wire connection, one "+"
wires. Block features two mounting supply and the other to power brake lights or a brake light
holes for #8 fasteners for installation on firewall or panel.
relay. Switches are rated at 4.5 Amps and have 1/8"-27 dry
seal mounting threads.
30-Amp Circuit Breaker ALL76251 ..... Male Bullet Terminals
ALL76212 ALL76252 ..... 6-32 Screw Terminals
Circuit breaker protects electrical circuits
similar to fuses but will cool and self-reset Brake Pressure
to maintain power to critical items such as Safety Switch ALL76255
headlights or ignition systems. Use circuit breaker Brake pressure switch is wired into the
to power accessories in a race car and to keep constant ignition system and kills power to ignition
power to ignition. Steel case and mounting bracket when a sudden spike in brake pressure is
provide durability and ease mounting to panels. #10-32 sensed in the event of an accident or emer-
threaded stud terminals include nuts and lock gency. Switch has an adjustable cut-off pressure from
washers. 700-1900 PSI and resets automatically when brakes are
released. A weatherproof cover protects the inner adjust-
30-Amp Relays ment screw and seals the 18" long pigtail leads. 1/8"NPT
Relays are commonly used to control higher male threads.
amperage components such as electric fuel
pumps, cooling fans or water pumps rated
up to 30 amps. Relays allow the use of a
lower amp switch to turn on or control a
component with a higher amp draw. A con-
nector with a wiring harness and installation
instructions are included.
ALL76186 ..... Standard Relay
ALL76188 ..... Weatherproof Relay
