Page 80 - 2019 Allstar Performance Parts and Equipment Catalog

ELECTRICAL, GAUGES & IGNITION
Battery Boxes
Universal, lightweight steel bat-
tery boxes may be welded or
bolted to the frame. Boxes
are available in two sizes
and include hold down
hardware.
ALL76100 ..... Full Size,
12" Wide x
7-1/4" Deep
ALL76101 ..... Short Style, 10"
Wide x 7-1/4" Deep
Bolt-On
Battery Boxes
Battery box has multiple 1/2"
mounting holes to bolt box
directly to the frame rail, inner
fender or firewall. Box can also be
fastened to round tubing using clamp-on
ballast brackets. Constructed of 13 gauge
steel, measures 11" wide x 7" deep and includes 3/8" bat- Kits Include:
tery hold down hardware.
ALL76102 ..... Clear Zinc
ALL76103 ..... Black
Stainless Steel Drop-Out
Battery Box ALL76105
The perfect battery box where
battery mounts under floor.
Eases battery service and replace-
ment. Box is 10-1/2" wide, 7"
deep, and 9-1/2" tall and will accept
most standard batteries.
Battery Hold Down Kit
For Optima ALL76107
Aluminum hold down kit provides
an attractive option for keeping
Optima 34/78 series batteries in
place. Battery not included.
Plastic Battery Box
ALL76099
Two-piece battery box fits up to
group 27 size batteries and includes
nylon strap with plastic mounting
brackets. Box may be bolted
through the bottom for more permanent
mounting. Cover is designed with quick lock
snaps to keep cover securely in place. Outside box dimen- chassis or create a secure ground wire location in
sions 16-1/8" x 9-5/8" x 10-7/8" tall. Inside dimensions
12-3/4" x 7-1/4" x 10" tall.
78 www.allstarperformance.com
Battery Cable Kits
Kits have everything
needed to connect a top
post style battery to starter
and include fine stranded,
ropelay copper cable
for best current carrying ALL76110
capabilities. Kits are offered with traditional red and black
ALL76100 cables or all black cables.
Single Battery Kits
ALL76110 ...... 2 Gauge Cable Kit With Red And Black Cables
ALL76111 ...... 2 Gauge Cable Kit With All Black Cables
ALL76114 ...... 4 Gauge Cable Kit With Red And Black Cables
ALL76115 ...... 4 Gauge Cable Kit With All Black Cables
Kits Include:
• 15' Positive Battery Cable • 8 Pcs. Ring Terminals 4) 5/16" & 4) 3/8"
• 2' Negative Battery Cable • 8 Pcs. Heat Shrink Tubing
• 1 Pair Battery Terminals
Dual Battery Kits
ALL76103 ALL76112 ...... 2 Gauge Cable Kit With Red And Black Cables
ALL76113 ...... 2 Gauge Cable Kit With All Black Cables
• 25' Positive Battery Cable • 14 Pcs. Ring Terminals 7) 5/16" & 7) 3/8"
• 8' Negative Battery Cable • 14 Pcs. Heat Shrink Tubing
• 2 Pair Battery Terminals
Solder Slugs
Use solder slugs to secure ring terminal ends to
battery cable. Individual pieces are the correct
amount of solder to be used for each size of
cable. Package of 10. ALL76131
ALL76131...... Slug For 2 Gauge Terminals
ALL76132 ..... Slug For 4 Gauge Terminals
Ring Terminals
Use to repair or build custom length
battery cables, or when installing a
battery disconnect switch. Terminals may
be crimped or soldered to wire. Sold in pairs
with heat shrink sleeving for a waterproof con-
nection.
Wire Size 5/16" Hole 3/8" Hole 1/2" Hole
ALL76128
ALL76117
ALL76116
2 Gauge
4 Gauge ALL76118 ALL76119 ALL76129
Impact Crimper ALL76135
Excellent for permanently crimping standard
cable ends to battery cables.
Ground Stud ALL76147
Steel ground stud welds to round tubing
providing a secure location for mounting NEW!
a negative battery cable. Weld stud directly to the
the foot box or engine compartment. Stud accepts
battery cables with 3/8" ring terminals.
