Page 92 - 2019 Allstar Performance Parts and Equipment Catalog

ENGINE Oil Coolers - Flange Mount Deck Mount Breather Tank

ALL36105
Adding an oil cooler to a vehicle
increases engine life and reduces
engine operating temperature. Spun aluminum tank has a flat NEW!
top and mounts on the bottom
Engine oil not only lubricates but side of your deck panel. Features a bottom
also removes a large amount of heat breather, drain petcock on the side near
from the engine. Top engine builders recommend and the bottom and a 3/4"NPT female bung
often require use of an oil cooler. Coolers have a 1/2"NPT near the top.
female bung commonly used for connecting a tempera-
ture sending unit or similar accessories and have built in
flanges for mounting to the deck underside of most dirt
late models, modifieds or other vehicles that would ben- Breather Tanks
efit from use of an oil cooler. Aluminum breather tanks are 11-1/2" x 3",
ALL30146 ..... Cooler With -10AN Fittings, 4" x 15" x 3-1/2" Tall include mounting bracket, clamp on breather
For Most Wet Sump Systems element, drain, and one or two 3/8"NPT
ALL30145 ..... Cooler With -12AN Fittings, 8-3/4" x 15" x 3-1/2" bung(s). ALL36109 can vent two systems.
Tall For Most Dry Sump Systems
Ideal for dry sumps and rear ends.
Oil Cooler Scoops ALL36108 ..... Tank With One Bung
ALL36109 ..... Tank With Two Bungs
Scoop mounts to the deck
of most race cars above the oil cooler Replacement Parts
forcing air through the oil cooler to aid ALL36202 ..... 1-1/2" Washable Breather ALL36109
ALL99030 ..... 1/4"NPT Petcock
cooling. Black plastic scoop has a carbon fiber ALL99031 ..... 3/8"NPT To 1/4"NPT Fitting
look and measures 11" x 7" with a 3" tall
opening and approximately a 1" mounting lip.
ALL23228 ..... Scoop With 7" Wide Opening
ALL23229 ..... Scoop With 11" Wide Opening Mini Breather Tanks
Small capacity, spun aluminum tank will vent
Linear dry sump tank, transmission or rear end. Tank
Engine Oil Coolers has a 1/4"NPT bung on bottom and a clamp
style bracket for mounting to chassis tubing.
Finned aluminum coolers have 3/4"NPT
ends and T-slots for easy mounting. ALL36140 ..... Clamps To 1-1/2" Dia. Tubing
ALL36141 ..... Clamps To 1-3/4" Dia. Tubing
ALL30142 ..... 3 Ft. ALL36103 ..... Replacement Breather Element ALL36140
ALL30143 ..... 4 Ft.
ALL30144 ..... 5 Ft.

SB Chevy Engine Diaper
Lifter Valley Vents ALL69011
ALL90065 Engine diaper will help
contain engine oil and
Lifter valley vents positively
vent the crankcase and fragments if an engine
eliminate oil drain-through failure occurs. Increase
and windage losses. When used with valley screens, vents safety and reduce the
prevent damage from broken valvetrain components. chance of control loss due to
Vents have 1/4"NPT threads and a 9/16" hex head to ease debris on the racing surface. Diaper wraps around oil pan
installation. Package of 8. and secures to header bolts. Diaper is NHRA approved
but is not designed for vehicles that require
SFI approved diapers. Diaper features a sewn-
in, non-replaceable oil absorbent pad and is
23" long x 12-1/2" high x 12" wide.

Replacement Parts ALL99043
ALL99043 ..... Replacement Tabs, 4-Pack
ALL99347 ..... Replacement Buckle, 1 Set
ALL69013 ..... Engine Diaper Pad, 22" x 30"
ALL99347
