Page 88 - 2019 Allstar Performance Parts and Equipment Catalog

ELECTRICAL, GAUGES & IGNITION

CD Ignition Coil ALL81230 LS Ignition Coils
High output ignition coil is specifically Direct replacement 40,000V
designed for use with capacitive discharge coils are a good choice
ignition systems. 40,000 volt coil is recom- when upgrading NEW! ALL81403
mended for use with Allstar Performance the OE ignition ALL81400
HP series distributors. Sturdy, high system in high performance
impact housing is epoxy filled to applications or when power adders are used. Sold each.
protect against vibration. Extruded ALL81400 ..... 1997-05 LS1/LS6 (Delco D580)
aluminum bracket eases mounting. Mounting hardware, ALL81401 ..... 1999-07 4.8/5.3/6.0L Truck (Round Style Delco
anti-vibration mounting pads, ring terminals and high D585)
temperature silicone boot are included. ALL81402 ..... 1999-07 4.8/5.3/6.0L Truck (Square Style Delco
D581)
ALL81403 ..... 2005-13 4.8/5.3/6.0/6.2/7.0L (Delco D510C/
High Output Coil ALL81232 D514A)
High output coil is specifically
designed for use with the high output
inductive storage ignition module LS Coil Mounting
found in Allstar Performance
Street/Strip series distributors. Brackets ALL26212
Delivering up to 40,000 volts, LS coil mounting
this coil has a male secondary tower which offers superior brackets are
boot and terminal retention and brass primary terminals black steel and
for maximum conductivity. Includes mounting hardware, sold as a pair.
ring terminals and high temperature silicone boot.

Canister Style MSD Box Mount
Ignition Coil ALL81234 ALL81330
45,000 volt, oil filled coil for electronic break- Box mount provides a
erless ignitions has low primary resistance and quick release method
112:1 turn ratio for improved throttle response for replacing MSD6420,
and more power at higher rpms. Coil fits all 6425, 6430 and other
standard O.E.M. brackets or Allstar ALL81236 ignition boxes with 7-1/2"
coil bracket. x 3-1/2" center-to-center
mounting dimensions. Kit includes aluminum box mount,
Coil Mounts four quick turn fasteners, springs and 1/8" aluminum
Use this lightweight, anod- rivets.
ized aluminum bracket to
mount canister type ignition Ground Straps
coil to chassis quickly and securely. ALL81322 The number one problem with
ALL81320 ..... Mount For 1-1/2" Tubing electrical systems is often related to poor
ALL81322 ..... Mount For 1-3/4" Tubing ground connections. Perfect for various
ALL81324 ..... Flat Mount 6 or 12 volt grounding applications.
ALL81324 Flexible, braided copper 12 gauge
Coil Bracket ALL81326 ground straps are 5/16" wide and have
Universal coil mount for standard size 3/8" non-insulated ring terminals on each end.
canister style ignition coils up to 2-1/4", ALL76330 ..... 9" Long
includes threaded cross bolt to aid in ALL76332 ..... 12" Long
mounting.

Blount Motorsports Photo: RW Motorsports James Shipka Photo: Robin Beachy
86 www.allstarperformance.com
